locations as possible and avoid practices such as "coiling" unused cable in a ceiling or
behind the display.

Contents

This package should contain:
1 x Local Unit (transmitter)
1 x Remote Unit (receiver)
2 x AC power adapter
1 x Instruction Manual

Connecting Your Signal Extender

This product is composed of two different units: the Local Unit and the Remote Unit. The
Local Unit takes the output from a VGA signal source (usually a computer) and transmits
it to the Remote Unit over Category 5 Ethernet cable. The remote displays (monitor,
projector) connect to the Remote Unit using standard VGA and headphone audio
connections (if desired) and displays the image from the local computer on the remote
displays.

Preparing Your Site

Before you can install the the product, you need to prepare your site.
1: Determine where the local computer will be located and set up the computer.
2: Determine where the remote display(s) will be located and place/mount them
appropriately.
3a: If you are using surface cabling, ensure you have enough Category 5 unshielded
twisted pair (UTP) Ethernet cabling to connect the Local Unit to the Remote
Unit's location, and that each end is terminated with a RJ-45 connector.
OR
3b: If you are using premises cabling, ensure that the Category 5 unshielded twisted pair
(UTP) Ethernet Cabling between the Local Unit and the Remote Unit has been
properly terminated in a wall outlet in each location and there is a
patch cable long enough to connect the Remote Unit and the Local Unit to
their respective outlets.
