- Page 1 Mini VGA over Cat5 UTP Extender and Receiver ST121UTPMINI Instruction Manual...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an en- dorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Instruction Manual Instruction Manual Table of Contents Introduction ..............1 Features..................1 Package Contents ..............1 Transmitter Unit .................2 Receiver Unit................2 Installation ............... 3 Transmitter Unit .................3 Receiver Unit................3 UTP Cat5 Cable .................4 Wiring Diagram ............... 4 Specifications ..............5 Technical Support ............6 Warranty Information ............ -
Page 4: Introduction
RJ45 connectors and supports transmission distances of up to 90m (275ft). The ST121UTPMINI is an out-of-box solution that includes both the local transmitter and remote receiver. The receiver is compact enough to be tucked away behind the display in tight spaces for any installation. -
Page 5: Transmitter Unit
Instruction Manual Transmitter Unit DE-15 VGA connector 3.5mm Audio mini-jack USB connector Receiver Unit EQ Adjustment dial DC Power connector DE-15 VGA connector 3.5mm Audio mini-jack *product may vary from photos... -
Page 6: Installation
NOTE: If the display has a VGA input that makes directly attaching the Receiver unit difficult, use an appropriate length VGA extension cable (i.e. StarTech.com ID: MXT101HQ3). If using audio, connect the 3.5mm audio cable to the display’s audio input, or separate audio receiver/speaker system. -
Page 7: Utp Cat5 Cable
Attach one end of the Cat5 cable to the transmitter of the St121UTPMINI and the other end to the receiver. The RJ45 Link LED on both units should light up to indicate the connection is detected. -
Page 8: Specifications
Instruction Manual Specifications ST121UTPMINI Video Signal VGA (RGBHV) 1 x DE-15 VGA male 1 x 3.5mm mini-jack Connectors (Local) 1 x USB type A 1 x RJ45 1 x DE-15 VGA male 1 x 3.5mm mini-jack Connectors (Remote) 1 x DC Power... -
Page 9: Technical Support
