Instruction Manual
Mini VGA Video and Audio Extender over Cat5
ST121UTPMINI
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/30/2011
Advertisement
Table of Contents
Related Manuals for StarTech.com ST121UTPMINI
Summary of Contents for StarTech.com ST121UTPMINI
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/30/2011...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges...
-
Page 3: Table Of Contents
Table of Contents Introduction ...............................1 Features ................................1 Package Contents .............................1 Transmitter Unit ............................2 Receiver Unit ..............................2 Installation................................3 Transmitter Unit ............................3 Receiver Unit ..............................3 UTP Cat5 Cable ............................4 Wiring Diagram ..............................4 Specifications ..............................5 Technical Support ............................6 Warranty Information ............................6 Instruction Manual... -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com Converge A/V Mini VGA over Cat5 UTP Extender and Receiver. Providing a high resolution point to point digital signage solution, the extender sends the video signal to a remote monitor / display or projector over standard 4 pair CAT5e UTP cable, using RJ45 connectors and supports transmission distances of up to 90m (275ft). -
Page 5: Transmitter Unit
Transmitter Unit DE-15 VGA 3.5mm Audio connector mini-jack USB connector Receiver Unit EQ Adjustment dial DC Power connector DE-15 VGA connector 3.5mm Audio mini-jack Instruction Manual... -
Page 6: Installation
NOTE: If the display has a VGA input that makes directly attaching the Receiver unit difficult, use an appropriate length VGA extension cable (i.e. StarTech.com ID: MXT101HQ3). 2. If using audio, connect the 3.5mm audio cable to the display’s audio input, or separate audio receiver/speaker system. -
Page 7: Utp Cat5 Cable
2. The UTP cable should not pass through any networking equipment, such as routers, switches, hubs, etc. 3. Attach one end of the Cat5 cable to the transmitter of the St121UTPMINI and the other end to the receiver. The RJ45 Link LED on both units should light up to indicate the connection is detected. -
Page 8: Specifications
Specifications ST121UTPMINI Video Signal VGA (RGBHV) 1 x DE-15 VGA male 1 x 3.5mm mini-jack Connectors (Local) 1 x USB type A 1 x RJ45 1 x DE-15 VGA male 1 x 3.5mm mini-jack Connectors (Remote) 1 x DC Power... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, conse- quential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
