Summary of Contents for CDA hn6730
- Page 1 Induction Hob Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model... - Page 3 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 surface prior to use. • Do not modify the appliance in any way as this will invalidate the guarantee and is potentially dangerous. • The hob top is not designed for any use other than cooking: any other use (e.g. as a worktop) is potentially dangerous and will invalidate the guarantee.
- Page 5 capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. • Children shall not play with the appliance. • Cleaning and user maintenance shall not be made by children without supervision.
- Page 6 • Warning: If the ceramic glass is broken or cracked do not use the appliance, turn off the electricity supply to avoid the possibility of electric shock. Contact CDA Customer Support. • There are no user-serviceable parts inside the appliance; all repairs must be performed by a suitably qualified service engineer or similar.
- Page 7 To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance with the regulations that apply to it. As such, CDA guarantee only that our product is compliant. With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the manufacturer or your attending physician.
- Page 8 Cooking On Induction The principle of induction cooking is based on magnetic effect. When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
-
Page 9: Using Your Hob
Using Your Hob Zones: 1. Front left 2.0kW 175mm 2. Back left 1.4kW 175mm 3. Back right 3.0kW 215mm 4. Front right 1.4kW 175mm Control panel: Zone timer Timer indicator Power key Zone indicator * Pause Booster On / Off Special Slider control programmes... - Page 10 The table below offers guidance as to what each power level is for. Power level Type of cooking Switched off Melting (butter/chocolate) or keeping food warm Keeping food hot or to heat small quantities of liquid Heat larger quantities of liquid (sauces etc.) Slow boiling, e.g spaghetti, soups, stews, potatoes Gentle frying Browning meats, frying fish, omelettes...
-
Page 11: Bridge Function
To change the power level after it has been set • To increase the power level for a zone: After touching the “Power key” for that zone, slide your finger along the slider toward the right. • To reduce the power level for a zone: After touching the “Power key”... -
Page 12: Pause Function
The heating level of the bridged zone is controlled just by using the front left “Power key” followed by the slider. To cancel the bridge function Touch the “Power keys” for the front and rear left zones at the same time again. - Page 13 Programmes” key instead of using the slider to set the power level, after touching the zone “Power key”. This function may be set on all four zones independently. The maximum duration for this function on each zone is 2 hours. Booster The hob is equipped with a booster function, allowing a higher power level than the maximum for approximately ten minutes.
- Page 14 preset period of time. When auto-heating has finished the power will reduce to the level set. • If no final power level is set, the auto-heat is switched off and the zone will remain on power level “9”. Timer The hob is equipped with a timer that allows a finish time to be set for the end of cooking on any zone, between a minimum of one minute and a maximum of 99 minutes.
-
Page 15: Minute Minder
• Use the slider to reduce the units of the time to zero. • Touch the “Timer” display again to confirm the units setting. • Use the slider to reduce the tens of units of the time to zero. • Touch the “Timer”... -
Page 16: Residual Heat Indicators
To cancel the beeper: touch the “Timer” display once. To cancel the minute minder • Touch the “Timer” display to select the timer. • Use the slider to reduce the units of the time to zero. • Touch the “Timer” display again to confirm the units setting. •... -
Page 17: Key Lock
Recall function Even after switching the hob off with the On/Off key , it is still possible to recall and re-use the settings that were last used. The recall procedure is: • Switch the hob back on using the On/Off key •... -
Page 18: Efficient Use Of Your Hob
switches off • Touch the “On/Off” key for approximately two second to switch the hob on. Efficient Use of Your Hob The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate zone depending on the size of the pan. -
Page 19: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 20: Troubleshooting
In the event of a fault with the hob, please advise CDA Customer Care of any fault code shown on the display Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY... - Page 21 The bottom diameter of the pan Place a larger pan on the is too small. cooking zone. The electronic system is Contact CDA Customer Care for “E” shows on the zone display. defective. advice. “Er03” shows on the zone One or more control keys are Clear any objects and clean display.
-
Page 22: Fitting The Hob
Fitting the Hob Unpacking the hob: Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 180mm away from any adjacent vertical surfaces, e.g. - Page 23 the hood above the hob must be at least 600mm (650mm is recommended) (Fig. 4). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, then that height is the minimum required. Wall furniture requirements: The minimum height of any cabinet immediately above the hob is 900mm.
-
Page 24: How To Install The Hob
How to Install the Hob: Top rail removed to allow air to exit. Recommended 560mm x 6mm Overall dimensions of the hob: Width: 590 mm Depth: 520 mm Worktop cut-out dimensions: Width: 560 mm Depth: 490 mm 1. Make the required hole in the worktop. -
Page 25: Mains Electricity Connection
Mains Electricity Connection Warning! this appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. This hob is intended to be connected to permanent fixed wiring by a double pole switch, having a contact separation of at least 3mm in all poles. - Page 26 connection box. • As the appliance is not fitted with an accessible plug, a means of disconnection from the power supply must be must be included in the fixed insatllation, in accordance with the installation regulations. • The inlet cable must be positioned so that it does not touch any of the hot parts of the hob or oven.
- Page 27 Any service call arising from incorrect installation may result in a charge. CDA and its representatives cannot be held responsible for any matters resulting from incorrect connection, or related to either the absense of an earth connection or a faulty earth connection.
- Page 28 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
