- Page 1 Induction Hob Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 (EMC) 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance with the regulations that apply to it. As such, CDA guarantee only that our product is compliant. With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the manufacturer or your attending physician.
- Page 5 Important • Do not use the hob if the glass surface is cracked or damaged to prevent the risk of electric shock. Disconnect it from the power supply. • Ensure that the power cable of a connected electrical appliance near the hob is not in contact with the cooking zones.
- Page 6 Cooking on Induction The principle of induction cooking is based on magnetic effect. When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
-
Page 7: Using Your Hob
Using your hob Zones: 1. Front left 2.2 - 3.5kW 220 mm x 190 mm 2. Back left 2.2 - 3.5kW 220 mm x 190 mm 3. Back right 2.2 - 3.5kW 220 mm x 190 mm 4. Front right 2.2 - 3.5kW 220 mm x 190 mm fig. - Page 8 Using Your Hob To switch the hob on • To switch the power on, touch and hold the "On/off sensor" (1) approximately one second. The hob will beep and all four cooking zone indicators, and both timer indicators, will show “0”. Please note: If a power level is not set within ten seconds, the hob will switch off automatically.
- Page 9 "On/off sensor" (1) for approximately one second. Please note: Any zones that are still hot to the touch will display an " " or " " provided the mains power supply is not interrupted. Booster The hob is equipped with a booster function on all zones, allowing a higher power level than the maximum for approximately ten minutes.
- Page 10 If the appliance's electronic circuits or induction coils overheat whilst the booster function is in operation then the function will be automatically deactivated and the zone will continue to operate at its nominal power. The booster function will be available again once the internal components have been cooled sufficiently.
- Page 11 Auto-heat Function • Every zone is equipped with an auto-heat function, which reduces the warming up time for the zone. To activate the auto-heat function on a zone • Simply touch the desired zone's indicator (7) and then set the desired power level using the heat setting slider sensor (5).
-
Page 12: Timer/Minute Minder
Timer/Minute Minder The hob is equipped with a timer that allows a finish time to be set for the end of cooking on any zone, between a minimum of 1 minute and a maximum of 99 minutes. This timer can be used separately for each zone, and an LED will indicate the zone positions for each of the active timers. - Page 13 • After approximately 10 seconds the selection will confirm and the time will begin counting down. • The timed zone LEDs are oriented in a similar way to the zones; • If no time is set within ten seconds, the timer indicators (10) will become inactive and the zone will continue cooking.
-
Page 14: Pause Function
To set the minute minder • Switch the hob on using the on/off sensor (1) if necessary but do not set a power level on any zone. • Touch the timer indicators (10) to activate the minute minder. The LED immediately above the timer indicators should illuminate. This is the minute minder LED. -
Page 15: Keep Warm Function
the hob, i.e. answering the door. To activate the pause function • At least one hob zone must be active. Press the pause function sensor (2). All cooking zone indicators will show a pause symbol and zone operation will halt. To deactivate the pause function and resume cooking •... - Page 16 To activate the keep warm function • Touch the desired zone’s indicator (7). Then touch the keep warm sensor (3) either once, twice or three times. • Touching the keep warm sensor (3) once will activate the 42°C heating level. •...
-
Page 17: Bridge Function
Bridge Function The hob is equipped with a bridge function which allows you to use two heating zones with just one zone's controls. This function is intended for use with pans such as fish kettles and is available for the two zones on the left side and the two zones on the right side. -
Page 18: Safety Key Lock
Safety Key Lock To prevent accidental use, the hob has a safety key lock which switches controls off temporarily or completely. The safety key lock can be activated when the hob is turned on but not when power has been switched off at, or the appliance disconnected from, the mains. Disconnecting the appliance from the mains will deactivate the safety key lock. -
Page 19: Efficient Use Of Your Hob
Efficient Use of Your Hob The hob is equipped with zones designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 20: Care And Maintenance
It is very important that the pans used on the hob are made of a suitable material and have the correct type of base. The base of the pan and the hob top must be clean before use to prevent any scratches on the hob top. - Page 21 2. Check that the mains supply has not been switched off. 3. Check that the fuse in the spur has not blown. In the event of a fault with the hob please advise CDA Customer Care. Contact CDA Customer Care...
-
Page 22: Troubleshooting
The hob is not working and the The electronics touched too briefly (less again and for longer display shows a non-standard are not functioning Call CDA Customer Care than a second) graphic correctly Sensor fields do not The hob is not working and the... - Page 23 Should any error code show on the zone displays, or the above steps not resolve an issue, please contact CDA Customer Care for assistance. Contact details are on page 21. IMPORTANT - PLEASE NOTE: In the event of any breakage, crack or cracking –...
-
Page 24: Fitting The Hob
Fitting the Hob Unpacking the hob: Installation above a cupboard unit Take care not to lose, drop or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 180mm away from any adjacent vertical surfaces, e.g. - Page 25 If fitting a cooker hood above the hob: If a cooker hood is to be installed above the hob, the height of the hood above the hob must be at least 600mm (650mm is recommended) (Fig.6). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, then that height is the minimum required.
-
Page 26: How To Install The Hob
Important notes: • Never place perishable foods, cleaning products or flammable items in the cupboard below the appliance. • If an oven is to be installed below the hob, the thermal safety system on the hob may not allow the hob to be used at the same time as a pyrolytic programme on the oven. - Page 27 If a splashback/worktop upstand is to be fitted, take this into account when cutting the hole. The minimum distance that the hob should be positioned away from the rear wall or splashback is 50mm. 2. Make sure that the worktop is clean and dust free and insert the hob 1 - Worktop into the cut-out opening.
-
Page 28: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. Live L: BN - brown Neutral N: BU - blue Earth PE: GNYE -green/yellow This appliance is intended to be... - Page 29 • This appliance is intended to be connected to the mains supply with a cable of cross sectional area 4mm 2 . • The current rating of the fuse or circuit breaker protecting this appliance should be marked on the socket outlet. •...
- Page 30 NOTES:...
- Page 31 Energy E ciency Information Attribute Symbol Value Units CDA model HN6841FR Type of hob Built in Number of cooking zones and/or areas Heating technology (induction cooking Induction zones and cooking areas, radiant cooking zones cooking zones, solid plates) For circular cooking zones or area: Ø...
- Page 32 Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
