- Page 1 Induction Hob Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance with the regulations that apply to it. As such, CDA guarantee only that our product is compliant. With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the manufacturer or your attending physician.
- Page 5 Important • Do not use the hob if the glass surface is cracked or damaged to prevent the risk of electric shock. Disconnect it from the power supply. • Ensure that the power cable of a connected electrical appliance near the hob is not in contact with the cooking zones.
- Page 6 Cooking On Induction The principle of induction cooking is based on magnetic effect. When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
-
Page 7: Using Your Hob
Using Your Hob Zones: Front left 3.7 kW 210mm 2. Back left 3.7 kW 210mm 3. Back center 3.7 kW 210mm 4. Back right 3.7 kW 210mm 5. Front right 3 . .7 kW 210mm 6. Front center 3.7 kW 210mm Control Panel: F: Special programmes G: Cooking zone... - Page 8 The table below offers guidance as to what each power level is for. Power level Type of cooking Switched off Melting (butter/chocolate) or keeping food warm Keeping food hot or to heat small quantities of liquid Heat larger quantities of liquid (sauces etc.) Slow boiling, e.g spaghetti, soups, stews, potatoes Gentle frying Browning meats, frying fish, omelettes...
-
Page 9: Bridge Function
To increase the power level for a zone, slide your finger along its slider (E) toward the right. To reduce the power level for a zone, slide your finger along its slider (E) toward the left. To turn the power off To switch off a single zone, touch the left hand end of the slider (E) for the zone no longer required. - Page 10 The symbols “ ” and “ ” against the power level displays for the 2 zones will go out and the zones will be independently controlled again. Pause function When one or more heating zones is active it is possible to pause all cooking temporarily without losing the settings for the individual zones.
- Page 11 Programme Used For Temperature Melting 42°C Warming 70°C Simmering 94°C Booster The hob is equipped with a booster function, allowing a higher power level than the maximum for approximately ten minutes. To turn on the booster function, touch the booster key for the zone required.
- Page 12 Set the cooking duration using the “-“or “+” key individually within five seconds. Touch and hold the “-“ or “+” key to scroll through the duration quickly. After five seconds, the dot in the timer display will start flashing and the countdown will start.
-
Page 13: Key Lock
Note that if any of the cooking zones is in use, pressing the “-“ and “+” keys together several times will cycle the choice through the minute minder and the zones you are using. Set the time using the “-“or “+” key individually within five seconds. Touch and hold the “-“... - Page 14 Use of the key lock when the hob is in use The key lock LED is illuminated to confirm the key lock is switched on and no adjustments can be made to any of the zones or the timer. It is possible to switch off the hob using the On/Off key when the key lock is on, for safety reasons.
-
Page 15: Safety Cut-Out
removed from the zone, or is unsuitable for use on induction hobs. The zone display will show “U” alternating with the power level until a suitable pan is placed on the zone. The zone will switch off after approximately one minute if no suitable pan is placed on the zone. Safety cutout The hob is equipped with a safety switch that automatically switches off zones after they have been operating for a certain period of time. -
Page 16: Efficient Use Of Your Hob
Efficient Use of Your Hob The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate zone depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 17: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 18: Troubleshooting
In the event of a fault with the hob, please advise CDA Customer Care of any fault code shown on the display Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY... - Page 19 Working normally turned off IMPORTANT - PLEASE NOTE: In the event of any breakage, crack or cracking – even minimal – of the vitroceramic glass, immediately disconnect your appliance to prevent a risk of electric shock and contact CDA Customer Care.
-
Page 20: Fitting The Hob
Fitting the Hob Unpacking the hob: Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 180mm away from any adjacent vertical surfaces, e.g. - Page 21 the hood above the hob must be at least 600mm (650mm is recommended) (Fig. 4). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, then that height is the minimum required. Wall furniture requirements: The minimum height of any cabinet immediately above the hob is 900mm.
-
Page 22: How To Install The Hob
How to Install the Hob: Top rail removed to allow air to exit. Recommended 750mm x 6mm Overall dimensions of the hob: Width: 900 mm Depth: 510 mm Worktop cut-out dimensions: Width: 750 mm Depth: 490 mm 1. Make the required hole in the worktop. -
Page 23: Mains Electricity Connection
Mains Electricity Connection Warning! this appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. This hob is intended to be connected to permanent fixed wiring by a double pole switch, having a contact separation of at least 3mm in all poles. - Page 24 The following diagram shows the mains connection: AC 220-240V 50/60Hz 48A Fig.6 When installing this product we recommend you seek the help of another individual. Appliance electrical rating: 11100W Any service call arising from incorrect installation may result in a charge.
- Page 28 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
