I. Congratulations Page ENGLISH II. Ensuring you get the best from your system Page 4 – 16 III. Important notes Page IV. BRITA, quality and satisfaction guaranteed Page 繁體中文 I. 恭喜您 頁碼 II. 確保獲得本系統最大效益 頁碼 22 – 34 III. 重要須知...
fi ltered water leaves your vegetables bursting with colour and fl avour The BRITA Tap has two levers. One for BRITA fi ltered water and BRITA cartridge the other for your regular unfi ltered hot/cold water.
II. Ensuring you get the best from your system Warranty The BRITA Tap Systems (Models: WD 3010, WD 3020, WD 3030 and WD 3040) are warranted to be free from defects in material and workmanship at the time of delivery. Any warranty claims will be voided if defective installation is deemed to have contributed to malfunction.
Page 5
Important: Please program the timer for 180 days. listed above (see fi g. 1) as well as the recommended tools. Note: Please ensure that you activate the electronic BRITA car- There are 7 steps to the installation. tridge exchange indicator with display during the day-time as the alert to change the fi...
Page 6
Press the DISPLAY button briefl y to activate the display. b Press and hold the START/RESET button for 5 seconds until a To install the BRITA Tap, fi rstly ensure you have all the components long beep sounds. required.
Page 7
Pull out both your kitchen tap and the hoses. You’re now ready to install the BRITA Tap (see fi g. 4). First of all, screw the shank (2) into the BRITA Tap (1). Screw the hoses into the dispenser (see fi g. 7).
Page 8
D Now connect the other end to the fi lter head inlet. This is labelled “IN” and marked with an arrow. Make sure that the washers are Then place the base (3) over the hole and fi x the BRITA Tap (1) in seated correctly! position using the supplied counter plate (4), the washer (5), the locking ring (6) and the hexagon nut (7).
Page 9
Step 5: Inserting the fi lter cartridge (see fi g. 9) A Remove the protective strap (1). B Insert the fi lter cartridge (4) vertically into the fi lter head (2). C Turn the locking handle (3) until you it clicks. Hot water Cold water supply...
Page 10
Using the mounting bracket, B Open the BRITA Tap and allow water to run until the fi ltered it should be installed only vertically, with the “UP” arrow on water runs clear and without any bubbles (at least 1 litre).
These models have an aerator with two integrated outlets. The hoses for kinks. Kinked hoses must be replaced. Inner one is for BRITA fi ltered water, the outer area for hot and cold The expected in- service life of the complete fi lter system is fi ve water.
Page 12
Gasket On Line 1/2" 2 mm CE + AU 1004674 1004710 Hose On Line 1/2" IT - 3/8" IT AU 1012909 Filter Head G3/8" BRITA Tap spare part 1004674 BRITA cartridge exchange indicator 1014490 Isolation Valve Spare Part AU 1012909...
Spare part Hose DN6 800 mm HF M8x1 - G3-8HN ASM 1012564 Aerator tap Set WD 3010 AU 1012560 1012565 Aerator fi ltrat Set WD 3010 1012567 Hose Set Hot and Cold WD 3010 AU 1012568 Montage Set WD 3010 1012564 1012565 1012561 1012568 1012567 1012562 (fi...
Page 14
Article No. Spare Part Name WD 3020 1012555 Aerator Set WD 3020 AU 1012556 Spare Part Mixer Cartridge 1012561 Spare Part Open-Close-Valve ASM 1012555 1012562 Spare part Hose DN6 800 mm HF M8x1 - G3-8HN ASM 1012558 Hose Set WD 3020 AU 1013529 Montage Set WD 3050 1012561...
Page 15
WD 3030/ Article No. Spare Part Name WD 3040 1012556 Spare Part Mixer Cartridge 1012553 Aerator Set WD 3030 AU 1012561 Spare Part Open-Close-Valve ASM 1012562 Spare part Hose DN6 800 mm HF M8x1 - G3-8HN ASM 1012553 1012558 Hose Set WD 3020 AU 1012552 Base Ring Set WD 3030/3040 1013529...
Page 16
Technical data of the A 1000 cartridge Technical data of the BRITA Tap Operating pressure 0.05 MPa to max. 1 MPa Operating pressure 0.1 MPa to max. 0.86 MPa Water intake temperature 4°C to 30°C cold water connection 4°C to 40°C warm water connection max.
Important Notice: Read this data sheet and compare the capabilities to your actual water treatment needs before purchasing. PERFORMANCE DATA SHEET FOR FILTER CARTRIDGE A 1000 Manufacturer Seller BRITA GmbH BRITA Water Filter Systems Heinrich-Hertz-Str. 4 Distributors Pty Ltd 65232 Taunusstein Level 9, 123 Epping Road...
Page 18
SUBSTANCE REDUCTION LEGEND: √ = pass The above listed Water Filter Cartridge has been tested and certifi ed under NSF/ANSI 42 for reduction of chlorine, taste and N/A = Not Applicable odour. The performance of this product has been verifi ed and substantiated as the test data summarised below indicates.
Page 19
• BRITA recommends that the fi lter system not be decommis- damage. sioned for a long period. If the BRITA Tap with A 1000 fi lter is not used for several days (2–3 days), we recommend that the Do not assemble near sources of heat and open fl ames. A stop fi...
Want to make the most of one of BRITA’s service offers? tory requirements. Give us a call! You can fi nd the contact details for your BRITA Customer Service team next to your country code on the back of this booklet.
Page 23
步驟 2:設定 BRITA 電子式濾芯更換顯示器 b 在嗶聲之後,輕按一下「DISPLAY」(顯示) 按鈕以啟動螢幕。 c 自從上次重新設定以來的剩餘天數便會顯示。 A 啟用: A 啟用: (注意:在電池電力完全耗盡後,最多只能維持 16 個小時。 在此之後,裝置將回復到原廠設定,且必須重新設定。請參閱要 請將隨附的電池 (2 顆 AA 電池) 裝入 BRITA 電子式濾芯更換顯示器 點 B。) 的電池槽內。 裝入電池後,會發出嗶聲長鳴。 G 安裝 G 安裝 B 首次設定: B 首次設定: 您可以使用隨附的 Velcro 掛勾及粘扣帶,將 BRITA 電子式濾芯更換...
Page 29
On Line 3/8" 2 mm CE + AU 防水襯墊 1004713 On Line 1/2" 2 mm CE + AU 防水襯墊 1004674 1004710 On Line 1/2" IT-3/8" IT AU 水管 1012909 G 3/8" BRITA 龍頭專用濾芯頭具 1004674 BRITA 電子式濾芯更換顯示器 1014490 逆止閥備用零件AU 1012909 1014492 限壓閥備用零件AU...
