- Page 1 Instructions for use...
- Page 2 Index ENGLISH I. Congratulations Page II. Quality from the very start Page III. Important notes Page IV. BRITA, quality and satisfaction guaranteed Page Installation Video...
- Page 3 I. Congratulations on your new BRITA Dispenser ® You are assured of B RITA quality and our commitment to our c ustomers. Your BRITA Dispenser, is the key to cleaner, clearer great tasting filtered water Next to hot and cold unfiltered water, your BRITA system offers many advantages • Great tasting filtered water at your fingertips • F iltered water is ideal for bringing out the full potential of your...
-
Page 4: Terms Of Warranty
II. Quality from the very start Terms of warranty The BRITA Dispenser is subject to the statutory guarantee of 2 years. A guarantee claim may be asserted only if all instructions in this handbook are followed and observed. Contents of the BRITA Water Filter Kit To ensure you get the best result from your BRITA Water Filter Kit, please follow these instructions carefully. Your BRITA Water Filter Kit includes the following (see fig. 1): 1. F ilter head with three settings including a convenient locking handle 2. Flexible wall mount 3. P 1000 water filter cartridge 4. BRITA Dispenser (design may differ from image shown) 5. BRITA Cartridge Status Indicator 6. Battery (CR2032) - Page 5 Setting BRITA Dispenser – easy installation number of reaction zones that changed their colour Before starting, please check that you have all the components capacity P 1000 up to 1200 L up to 600 L up to 400 L listed above (see fig. 1) as well as the recommended tools. P 3000 up to 3400L up to 1700 L up to 1100 L There are 7 steps to the installation. German Carbonate up to 10 10 to 17 above 17 dH Hardness [°dH] Prior to installation, read the "Technical Data" (chapter 7) English Carbonate up to 13 13 to 21 above 21 and the "Important Notes" (chapter 9). The system cannot Hardness [°eH] be installed with a low pressure boiler as this might lead to French Carbonate up to 18 18 to 30 above 30 water damages. After storage and transport below 0°C, Hardness [°fH]...
- Page 6 (fig. 5) B Initial programming of the BRITA Cartridge Status Indicator: Depending on the setting you chose for the filter head (step 1), you will programm the BRITA Cartridge Status Indicator as 1 LED 2 LEDs 3 LEDs follows (see fig. 5): water hardness setting (HARDNESS) C a Push the button on the right side (HARDNESS) to choose the water hardness. If you push the button once, two yellow LEDs...
- Page 7 - Y ellow light: 90 % of the filter capacity has been used. R emember WD 3020 to buy a new replacement filter cartridge. - Red light: The filter cartridge needs to be changed. 1. B RITA Dispenser with 3 hoses E Reprogramming the BRITA Cartridge Status Indicator 2. B RITA Cartridge Status Indicator If the maximum volume is reached or the cartridge has been used 3. O -Ring for 12 months, the BRITA Cartridge Status Indicator’s LED will start 4. S hank flashing red (only if BRITA lever is in the filtering position). 5. J oint (Is only necessary for installa- In this case the filter cartridge should be replaced (chapter 4). Once tion of the dispenser if you directly the cartridge has been replaced the BRITA Cartridge Status Indica- mount it onto your sink. If you...
-
Page 8: Step 4: Attaching The Hoses
A C onnect supplied T-piece on your cold water supply We recommend placing a suitable container under the water a) I nsert one 3/8" gasket into the female nut of the supplied T-piece. supply as there will be water left in the hoses which will run b) Connect this end of the T-piece to your cold water supply. down when you unscrew them. If you do have an additional free 3/8" cold water supply for d) Unscrew your kitchen tap – there is no standard mounting but the BRITA Dispenser in your kitchen, you do not need to in general a pipe wrench will help you to unmount it. install the supplied T-piece! e) Pull out both your kitchen tap and the hoses. If your cold water supply does not fit the 3/8" connector of the T-piece, use the supplied adapter if required. Please B You’re now ready to install the BRITA Dispenser. insert the 1/2" gasket into the female nut of the adapter first. First of all, screw the shank (4) into the BRITA Dispenser (1). Your Water Filter Kit comes with two 1/2" adapters. Please Screw the hoses into the dispenser (see fig. 8). go to your nearest supplier for adapters in other sizes. Screw the M8 connector of the hose with the blue stripe into the hole C . B Connect the hose with the blue stripe to one side of the T-piece. Screw the M8 connector of the hose with the red stripe into the C Take the hose with two 3/8" connectors. Insert the 3/8" gaskets hole H. into the respective female threads of the two hose ends. Screw the M8 connector of the 800 mm hose into the hole B. C onnect one end with the free side of the T-Piece. WD 3020/ W D 3030/ W D 3040 and WD 3050 D Now connect the other end to the filter head inlet. This is labelled... - Page 9 Step 5: Inserting the filter cartridge (see fig. 10) A Remove protective strap (1). B Insert the filter cartridge (4) vertically into the filter head (5). C Turn the locking handle (3) until you feel it engages. Cold water supply Hot water supply (fig. 9) The max. tightening torque for the G3/8" connections may not exceed 14 Nm! Only hose connections with gaskets (13) may be used – hoses with conical screw connections damage the connections of the filter head and invalidate any warranty claims! (fig. 10) The filter cartridge can only be inserted when the locking handle is open. Make sure that the filter cartridge is positioned correctly. ENGLISH...
-
Page 10: Replacing The Filter Cartridge
(see fig. 11) correctly and all the parts are fitted. Place a suitable container under the cartridge to catch any leakages. A Turn on the cold and hot water supplies and check the system During assembly, note the installation dimensions, bending carefully for any leaks. radii of the hoses and dimensions of the accessories. The system can be operated vertically and horizontally. When B Open the BRITA Dispenser and allow water to run until the fil- using the wall mount, install vertically only! tered water runs clear and without any bubbles (at least 2 litres). A Attach the wall mount in place using the two matching screws and use two wall plugs, if necessary, depending on the type of Replacing the filter cartridge wall. B Engage the filter head (2) in the wall mount (1). Please use the If the maximum volume is reached or the cartridge has been used fixation holes (4). -
Page 11: Maintenance
Prior to exchanging the filter system, read the Technical Data bracket) (chapter 7) and Important Notes (chapter 9). Operating position Horizontal and vertical Regularly clean the outside of the filter system with a soft, damp Water inlet connection G3/8" cloth. Water outlet connection G3/8" Do not use any abrasive chemicals, cleaning solutions or astringent cleaning agents. Technical data of the BRITA Dispenser Technical data of the P 1000 and P 3000 cartridge Operating pressure 0.5 bar to max. 10 bar cold water connection 4°C to 30°C Operating pressure 2 bar to max. 8.6 bar warm water connection max. 70°C Water intake temperature 4°C to 30°C flow rate ≥ 9 L/min... -
Page 12: Troubleshooting
Troubleshooting For models WD 3030 and WD 3040 only A No water flow These models have an aerator with two integrated outlets. The Inner one is for BRITA filtered water, the outer area for hot and cold Cause: Water intake closed. water. As with every tap aerator, there can be limescale build-up in Troubleshooting: O pen the water intake at the upstream shut-off the outer area. Therefore it is recommended to clean the aerator valve or by closing the locking handle (3) on the on a regular basis. For cleaning: Unscrew the cap on the end of the filter head (5). Check hoses for kinks. dispensers neck. The aerator is connected to a silicon hose. Detach it carefully and clean the aerator (e.g. with vinegar). After cleaning B No or low water flow in spite of open water intake connect the long, thin part on the back of the aerator carefully with Cause: Mains pressure too low. - Page 13 Spare Part Name WD 3020 Article No. Spare Part Name 1004715 Gasket On Line 3/8" 2 mm CE + AU 1012554 1004713 Gasket On Line 1/2" 2 mm CE + AU 1004699 Hose On Line 3/8" IT - 3/8" IT CE 1015771 Filterhead G3/8 3-way LED CE 1004690 Adapter 1/2" IT - 3/8" ET 1005821 T-piece 3/8" 1015771 1016311 1012556 1016282 1004699 1015754 1005821 1004715 1013529 1012557 1004690 (fig. 13) (fig. 14) 1012562 1004713 Article No.
- Page 14 Spare Part Name 1012550 Aerator Set WD 3030 CE 1014609 Aerator Set WD 3050 1012556 Mixer Cartridge 1012550 1012552 Base Ring Set WD 3030/3040 brushed 1014609 1014608 Base Ring Set WD 3050 1012557 Hose Set WD 3020 CE 1013529 Assembly Set WD 3050 1012562 Hose DN6 800 mm HF M8x1 - G3-8HN ASM 1015754 BRITA Cartridge Status Indicator spare part 1016311 Valve LED ASM spare part 1016282 Lever WD3020-3040 spare part 1016311 1012556 1016282 1015754 1012552 brushed 1014608 1012557 1013529 1012562 (fig. 15) ENGLISH...
-
Page 15: Important Notes
III. Important notes Important notes Optimum use Protect the P 1000 water filter cartridge from direct sunlight and • B RITA recommends that the filter system is not left unused for a mechanical damage. Do not assemble near sources of heat and long period. If the BRITA Dispenser is not used for several days open flames. A stop valve must be installed before the filter system (2–3 days), we recommend that the filter system be flushed with intake hose. The BRITA Dispenser is only suitable for domestic the flushing volume X indicated in the table below. After stagna- use. tion periods of over 4 weeks, the filter should be flushed with flushing volume Y. Please also note the maximum usage period of Only water of drinking water quality may be used as intake water the filter cartridge is 12 months, irrespective of the actual volume for the BRITA water filter system. The BRITA water filter cartridge used. is only suitable for cold water use within the supply water tem- perature stated in chapter 7 . No microbiologically impaired water Similar to the conventional taps, before using you should let water or water of unknown quality may be used without appropriate rinse through for a short period so you can enjoy your BRITA filtered disinfection. water. The system cannot be installed with a low pressure boiler. Flushing volume X after 2–3 days stagnation Flushing volume Irrespective of the water used, you should use stainless steel P 1000 2 Litres utensils or kettles with stainless steel heating elements. This is of particular importance to people who are sensitive to nickel. P 3000 3 Litres... -
Page 16: Exclusion Of Liability
IV. B RITA , quality and satisfaction guaranteed ® Correct disposal of the BRITA Cartridge Status The BRITA service hotline cares Indicator Do you have any questions about your BRITA product? Every BRITA Cartridge Status Indicator has a use- Or on the subject of water filtration? Give us a call! ful life of approx. 5 years. At the end of the useful You can find the contact details for your BRITA customer service life of the Status Indicator, remember that it must team next to your country code on the back of this booklet. be disposed of according to the applicable regula- tions and statutory requirements. The best side of water: www.brita.net Are you looking for your nearest BRITA retailer? Do you want more detailed information about BRITA products? Or about the BRITA company? Exclusion of liability Want to make the most of one of BRITA’s service offers? Up-to-date...
