CONTENTS 1. FEATURES............... 3 2. GENERAL CONTROLS AND INDICATORS ....4 MULTIFUNCTIONAL INDICATOR LIGHT ................5 RINGER VOLUME SWITCH ....................6 ALPHA-NUMERIC KEYPAD ....................6 CRADLE SWITCH ......................... 6 ELECTRONIC VOLUME CONTROL ..................6 RECALL KEY ........................7 HANDSFREE / HEADSET KEY AND INDICATOR (WITH AUTO-DECTION) ......7 MUTE KEY AND INDICATOR ....................
Page 3
USING THE MEMORIES ..................... 13 6. MEMORY FEATURE OPERATION ....... 14 STORING A NUMBER ......................14 DIALING A NUMBER ......................14 CASCADE DIALING ......................14 DIGIT CAPACITY ......................... 14 STORAGE TIME ........................14 7. INSTALLATION .............. 15 UNPACKING ........................15 GENERAL SETTING-UP .....................
1. FEATURES • Tone dialing • Handsfree speakerphone • Built in headset socket to suit a wide range of headset types • 10 one touch memory keys (non-volatile memories) • Adjustable Headset/Handset/Handsfree hearing level with electronic buttons volume • Mute Key and indicator – for privacy on both Handset, Handsfree and Headset mic •...
• Telstra Customnet compatible • Line powered, unaffected mains power interruption • REN (Ringer Equivalence Number) = 0.68 allows multiple parallel devices on the same line without loading incoming ring • Alpha-numeric keypad allows full access to services that require the entering of numerals and letters •...
Page 6
HEADSET MIC ADJUST CONTROL LINE HEADSET SOCKET SOCKET WALL RINGER MOUNT HI / LOW / OFF SWITCH HOLE HANDSET SOCKET MESSAGE WAITING & HEADSET POLARITY SWITCHES FIGURE 1 : BOTTOM VIEW...
MULTIFUNCTIONAL INDICATOR LIGHT There are two different functions: Ring Indicator: Flashes when the telephone rings with an incoming call Message-Waiting Indicator: Illuminates when a message is waiting in your voicemail system (depends on system compatibility). The built-in Message Waiting option suits any neon (80 VDC) type message waiting system and also the telephone has Ericsson BP250 Message Waiting built-in (other system types are optional extras).
ELECTRONIC VOLUME CONTROL Used to adjust 4-steps the volume of the HANDSET, HEADSET or HANDSFREE hearing level. Press (vol-) or (vol+) to adjust the volume. Adjusting this control does not affect your outgoing voice level. RECALL KEY For use with host telephone systems to invoke special network facilities such as call- hold or call-transfer available in your system.
Pause Function The Pause command may be needed if your phone is connected to any network where a pause is required (e.g. between internal and external dial tones). For manual dialing: 1. Lift HANDSET 2. Dial any digits required before the pause 3.
3. HANDSFREE OPERATION HANDSFREE MICROPHONE Located at the front of the phone (Figure 1), its function is to reproduce your voice as you speak to the other party while your telephone is in HANDSFREE mode. Positioning of the telephone, and therefore the MICROPHONE, is important to ensure the best reproduction of your voice.
HINTS FOR HANDSFREE OPERATION As a courtesy, tell the other party that you are using the Handsfree function. He / She may or may not want people other than yourself to hear the conversation. A quiet environment ensures best Handsfree performance. When HANDSFREE is used in a noisy room or near a noise generating device ( for example, a TV set ) all or part of the message may be interrupted and cannot be heard.
4. HEADSET OPERATION The telephone can be configured to suit many different headsets - please consult the INSTALLATION section for details to get the best performance from your headset. CLARIA "ALERT" FEATURE The telephone is designed to support the "Alert" feature available on the Claria headset. When pressing the HANDSFREE / HEADSET key on the telephone, the "Alert"...
Training Mode Allows a supervisor to monitor a trainee during a call. 1. During a trainee's call the supervisor may lift the HANDSET (HANDSFREE / HEADSET indicator will turn off) 2. Quickly press the HANDSFREE / HEADSET key and the indicator will illuminate 3.
Depending on your telephone system, this may or may not be required. If in doubt, check with your system supplier or Interquartz dealer, as failure to observe your system's requirements may lead to difficulty in making outgoing external calls. If you have determined that a pause is required by your host system, please refer to the PAUSE Function section to ensure correct usage of the PAUSE button.
6. MEMORY FEATURE OPERATION Located at the top of the keyboard, the ONE-TOUCH MEMORY Keys provide easy dialing of often-used numbers. Each memory can store 32 digits and can store , Pause and commands. STORING A NUMBER : 1. Lift HANDSET or press HANDSFREE / HEADSET KEY 2.
2. To enable the HANDSET to be supported in the cradle, follow the procedure shown in (Figure 2) to reverse the HANDSET RETAINER. 3. NOTE: The WALL MOUNT BRACKET and MODULAR WALL JACK illustrated in (Figure 2) are available from your authorised Interquartz dealer and can be ordered as "Wall Mount Kit No.3". HEADSET Connect a headset to the headset socket at the rear, and set the HEADSET POLARITY SWITCH and HEADSET MIC ADJUST CONTROL described in this section.
Page 17
1. Use your thumb to press the 2. Push the HANDSET RETAINER HANDSET RETAINER out of the slot. 3. Rotate the HANDSET 4. Insert the HANDSET RETAINER RETAINER by 180 back into its slot. FIGURE 2: WALL MOUNTING FIGURE 2 : WALL MOUNT BRACKET...
Page 18
WALL-MOUNT BRACKET OPTIONAL NOT INCLUDED WITH PHONE LUG "B" LUG "A" MOUNTING HOLE "E" PIVOT FOR SWING-OUT PLATE USED FOR MODEL IQTEL 25 LUG "C" LUG "D" MOUNTING HOLE "F" Please note: 1. This wall bracket may be secured onto the wall by using mounting holes "E" and "F" 2.
LINE CONNECTION This telephone is supplied with a RJ45 Plug as the wall plug, with the centre pair being reserved for speech and signaling. Other types of plugs and cords are available on request. TECHNICAL ADJUSTMENTS - FOR CORRECT OPERATION MESSAGE WAITING LIGHT COMPATIBILITY Located in the Multifunctional Indicator Light, the Message Waiting Light can be optionally configured at time of order to be compatible with most host telephone systems on the...
If you sound too loud on the headset, adjust the microphone sensitivity (turn anti- clockwise) so that your voice level when using the HEADSET matches that of the HANDSET. Clockwise rotation increases the HEADSET mic output level. Please see (Table 1) as a guide to the correct settings for most popular headsets. HEADSET POLARITY SWITCH Located on the underside of the telephone, this switch provides compatibility with the two commonly-used headset wiring standards.
"suspect" telephone. Test the "suspect" telephone on a known good line. If the fault still occurs, the fault is in the "suspect" telephone. Consult your Interquartz dealer for further advice if necessary.
: stoves, air conditioners, refrigerators, window frames and sinks. 10. WARRANTY - 3 YEARS Interquartz (A'Asia) Pty Ltd warrants the original purchaser against failure, under normal usage and in the environment and network for which it was designed, resulting from defective material and workmanship at time of manufacture for a period of THREE YEARS from the date of purchase.
