Page 1: Quick Start Guide
P-2000W_V2 VoIP Wi-Fi Phone Quick Start Guide Version BV_1.0 1/2006 ZyXEL... - Page 2 ZyXEL P-2000W Quick Start Guide Please Read This First Thank you for purchasing this ZyXEL VoIP Handset. To start using this phone, you will need a BroadVoice account. If you have already subscribed to BroadVoice and have received this box as a result of that order, simply follow the steps in this Quick Start Guide to get set up.
- Page 3 ZyXEL P-2000W Quick Start Guide About ZyXEL Founded in 1989 as a modem developer, ZyXEL is now one of the world's leading broadband hardware solutions specialists. As a broadband industry leader, ZyXEL has developed state-of- the-art Voice over IP technology, offering complete and full-featured VoIP Equipment for our customers’...
-
Page 4: Before You Begin
ZyXEL P-2000W Quick Start Guide Before You Begin Before you can begin using Your P-2000W Phone, you will need: A 802.11b or 802.11g wireless router An existing High-Speed Internet connection: DSL, Cable, Satellite, etc. A computer with a web browser for BroadVoice sign-up at www.broadvoice.com High-Speed Internet Access... - Page 5 ZyXEL P-2000W Quick Start Guide Getting to Know Your P-2000W VoIP Wi-Fi Phone 1. LCD Screen: This screen is used to display information and navigate the phone’s menus. 2. Left Selector key: This key is used to select menu options from the LCD Screen. It is also a shortcut to the phone’s Menu system.
- Page 6 ZyXEL P-2000W Quick Start Guide Page 6...
-
Page 7: Table Of Contents
ZyXEL P-2000W Quick Start Guide Ready to start talking? Follow these quick steps to get started: Charge your Phone Setting Up BroadVoice on your Phone Connect the Phone to your Wireless Network Setting Up WEP on your Phone (Optional) Making and Receiving Calls Page 7... -
Page 8: Charge Your Phone
ZyXEL P-2000W Quick Start Guide Charge your Phone Remove the battery cover. Press down on the silver button and slide the battery cover with your other hand as shown. Insert battery as shown. Insert the bottom of the battery first, and push the top of the battery into the phone. -
Page 9: Setting Up Broadvoice On Your Phone
ZyXEL P-2000W Quick Start Guide Setting Up BroadVoice on your Phone ZyXEL has partnered with BroadVoice to provide you with VoIP service, allowing you to make and receive voice calls over the Internet. You will need the “MAC Address” from the phone for UPC Code your BroadVoice account, which can usually be found on the bottom of the phone’s box near the UPC code. - Page 10 ZyXEL P-2000W Quick Start Guide # Scroll to 3.MAC Address using the Down Arrow and press the Left Selector key Write down the MAC address shown on the phone. You will need this information to register with BroadVoice. From your computer, open a web browser and type www.broadvoice.com in the address bar.
-
Page 11: Connect The Phone To Your Wireless Network
ZyXEL P-2000W Quick Start Guide Connect the Phone to your Wireless Network If the screen displays “Net failed” with an error code, the phone is not connected to your wireless network. Use these steps to get your phone connected: From the main menu screen, press Left Selector key to enter the Menu options. - Page 12 ZyXEL P-2000W Quick Start Guide Press the Left Selector key to choose your wireless network. The phone will display “OK” and return to the Wireless Menu. Press the Right Selector key twice to save your new settings. An hourglass will appear on the LCD Screen, indicating your phone is saving the new settings.
-
Page 13: Setting Up Wep On Your Phone (Optional)
ZyXEL P-2000W Quick Start Guide Setting Up WEP on your Phone (Optional) If you use Wired Equivalency Protection (WEP) to protect wireless traffic on your network, follow these steps to connect your P-2000W to your wireless network: Continuing from the previous section, press the Left Selector key to choose your wireless network. - Page 14 ZyXEL P-2000W Quick Start Guide Enter your wireless network WEP key through selecting keypad modes and the keypad. You may need multiple keypad presses to enter letters. For example, to enter a lowercase “b”, press the Down Arrow key to select lowercase mode, then press the “2”...
-
Page 15: Making And Receiving Calls
ZyXEL P-2000W Quick Start Guide Making and Receiving Calls To make a call, first ensure that the main menu displays “Registered”. Then, dial the desired number using the keypad and press the green Call key Press the red Power/ End key to terminate the call. -
Page 16: Feature Access Codes
ZyXEL P-2000W Quick Start Guide Voice Messaging To access your voice mail and greeting options, use the chart below as a quick reference. Voice Portal Voice Mail To access your To access the voice mail menu from an outside line: voice portal from Dial your BroadVoice telephone number your BroadVoice... - Page 17 ZyXEL P-2000W Quick Start Guide *90 – Call Forwarding Busy Activation: automatically redirects all incoming calls to another destination number when your phone is busy. Dial *90, and at the prompt, enter the destination phone number. A recording indicates successful forwarding. *91 –...
- Page 18 ZyXEL P-2000W Quick Start Guide *69 – Call Return: Use this code to call the last party that called you, regardless of whether or not you answered their call. Simply dial *69, and the phone does the rest. *74 – Speed Dial 8: enables you to call your party by dialing a one-digit code. Simply dial *74 followed by the one-digit speed dial code for your party, the number you want to program to that code, and finally the pound (#) key.
-
Page 19: Troubleshooting
ZyXEL P-2000W Quick Start Guide *99 – Clear Voice Mail Message Waiting Indicator: use this code to clear any audible or visual “new voice mail” indicator from your phone. Dial *99, and a message will indicate successful activation – the “new message” indicator will be cleared. Troubleshooting Basic Troubleshooting Use the following questions and answers if you cannot use your P-2000W handset:... - Page 20 ZyXEL P-2000W Quick Start Guide Phone Does Not Ring: Ensure that the ring volume on the handset is turned up by using the Left Selector key to enter the phone’s Menu. Use the Up and Down Arrow keys to go to menu 6.
- Page 21 ZyXEL P-2000W Quick Start Guide Rebooting your Equipment Sometimes it may be necessary to reboot your equipment after setup to get things working. Use these following steps to reboot your equipment properly: 1. Power down your computer, wireless router, P-2000W handset, and broadband modem. 2.
- Page 22 Fax: (714) 632-0858 Email: support@zyxel.com http://www.us.zyxel.com/support ZyXEL Thanks for choosing BroadVoice and the BroadVoice logo © 2006 BroadVoice, Inc. All rights reserved. ZyXEL, the ZyXEL supergraphic, and the ZyXEL logo © 2006 ZyXEL Communications, Inc. All rights reserved. Page 22...
