Technical Specifications

General
External Power Supply
Connector
Power Consumption
Operating Temperature Range
Relative Humidity Range (Non-Condensing)
Dimensions
Weight
Connections
10/100 Ethernet Port
RS232 Port 1
AUX Port
RS232 Port 2
Camera Inputs
Monitor-A Output (Y/C)
Monitor-B Output (Y/C)
Monitor-A Output (Composite)
Monitor-B Output (Composite)
Monitor-C Output (Composite)
Monitor-D Output (Composite)
Monitor-E Output (Composite)
RS485 Port
IEEE 1394 Firewire Port
SCSI Port
Alarm I/O Port
0150-0242C
12 Volt DC. 70 Watt (5.8 Amp)
2.1mm barrel connector, center positive.
60 Watt nominal (single disk).
Operating: 0 to 40°C. Storage: -20 to +60°C.
Operating: 10% to 80%. Storage: 10% to 95%
17.5 x 14 x 2.5 Inches. 1.5 U, 19-inch rack unit.
12 Lbs.
RJ-45 Connector.
DB-9 Male Connector.
DB-9 Male Connector. Use supplied Matrix Audio PCB.
RJ-45 Connector.
BNC connectors. Auto Terminating. Color & Mono.
4-pin Mini-DIN Connector.
4-pin Mini-DIN Connector.
BNC Connector
BNC Connector
BNC Connector
BNC Connector
BNC Connector
Two Looping RJ-45 Connectors
6 position IEEE 1394 Socket
50 pin, High Density SCSI-2 female connector.
Use Supplied DB-25 PCB connector.
