3.23 The SystemView Menu

The SystemView Menu Overview
The SystemView menu is provided so that users may quickly view global
software and hardware settings.
About DVMR menu: This menu provides information
such as:
•
Model Designation
•
Serial Number
•
Hostname
•
Software Version
•
Software Date
•
Boot Code Version
•
Hard Disk Size
•
IP Address
•
Hardware Address (MAC).
•
DHCP Lease Expiration Date
View Screens 1 through 9: These menus provide an overview of the units current operating
parameters and the menu settings selected by the user or installer. Each View Screen is described in
the following tables. The default values are bolded and italicized.
The View Screens
View Screen 1
Alarm Input
•
Enable/Disable: 1 = Enabled, 0 = Disabled
•
Normally Open or Normally Closed: 0 = Open, C = Closed
•
Macro: Macro number if activated.
Alarm Action
•
Freeze: 1 = Freeze, 0 = No Freeze
•
Cameras: Primary camera in alarm and three associated cameras.
•
Relay: 1, 2, 1+2, or None.
•
Intrusion AND/OR: AND, OR
0150-0242C
Model:
Serial Number:
Hostname:
Software Version:
Software Date:
Boot Code Version:
Disk Size:
IP Address:
Hardware Address:
DHCP Lease Expires:
64
About DVMR
View Screen 1
View Screen 2
View Screen 3
View Screen 4
View Screen 5
View Screen 6
View Screen 7
View Screen 8
View Screen 9
DVMRe-16CM
D406-TM2-250419
D406TM2250419
VER 5.00
Mar 25 2003 16:40:18
VER 1.03
163.93 GB
3.18.173.10
BA-BE-C6-7E-FA-CE
No Lease or Date
OK
Kalatel DVMRe Matrix
