2. From this point, begin recording the desired keystroke sequence. Record up to 32 keystrokes. If
32 keystrokes are exceeded, the unit will end the macro recording automatically.
3. When finished programming, press the Function button then the Enter button to end the macro
recording. A form is provided in section 10 to keep track of recorded macro functions.
Keystroke count while in the menu system: While recording a macro, entering the
NOTE
menu system, changing multiple menu items, and exiting the menu system are only
counted as one keystroke. Using the Jog to navigate the menu system does not count
as keystrokes. Once the menu system has been exited, re-entering the menu system
will count as a second keystroke.
Not all menu items can be programmed using macros. For a complete list of macro
programmable menu items, see the table below.
During macro recording, the following button combinations perform special functions.
Button Sequence
Function then 1.
Function then 2.
Function then 3.
Function then 4.
Function then 5.
Function then 6.
Function, Function, then
Submacro number.
Function then Enter.
Macro Excluded Features
The following core features or settings cannot be programmed by Macro.
•
Disk Maintenance.
•
Erase Archive Medium.
•
POTS Setting.
•
Ethernet Setting.
•
RS485 Network Address.
•
Front Panel Lock/Unlock.
•
Record Timer.
0150-0242C
Resulting Action
Activate Relay 1 output.
Reset Relay 1 output.
Pause macro for 1 second.
Pause macro for 5 seconds.
Activate Relay 2 output.
Reset Relay 2 output.
Program a specific submacro to activate when the macro is run.
End macro recording
