- Page 1 Induction Hob Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model... - Page 3 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 surface prior to use. • Do not modify the appliance in any way as this will invalidate the guarantee and is potentially dangerous. • The hob top is not designed for any use other than cooking: any other use (e.g. as a worktop) is potentially dangerous and will invalidate the guarantee.
- Page 5 capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. • Children shall not play with the appliance. • Cleaning and user maintenance shall not be made by children without supervision.
- Page 6 • Warning: If the ceramic glass is broken or cracked do not use the appliance, turn off the electricity supply to avoid the possibility of electric shock. Contact CDA Customer Support. • There are no user-serviceable parts inside the appliance; all repairs must be performed by a suitably qualified service engineer or similar.
- Page 7 To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance with the regulations that apply to it. As such, CDA guarantee only that our product is compliant. With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the manufacturer or your attending physician.
- Page 8 Cooking On Induction The principle of induction cooking is based on magnetic effect. When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
-
Page 9: Using Your Hob
Using Your Hob Zones: 1. Front 1.4 kW 175 mm 2. Back 1.4 kW 175 mm Control panel: 3. Power key 4. Timer display 5. Zone selection keys 6. Zone displays 7. - key 8. + key 9. Timer control light Fig.1... - Page 10 Using Your Hob The table below offers guidance as to what each power level is for. Power level Type of cooking Switched off Melting (butter/chocolate) or keeping food warm Keeping food hot or to heat small quantities of liquid Heat larger quantities of liquid (sauces etc.) Slow boiling, e.g spaghetti, soups, stews, potatoes Gentle frying Browning meats, frying fish, omelettes...
- Page 11 To turn the power off To switch off a single zone, touch the “Selection” key for the zone no longer required. Touch the “-” key until the zone display shows zero. When both zones are at zero, the hob will switch off automatically after approximately ten seconds.
-
Page 12: Minute Minder
• At the end of the set time, the selected zone will switch off and the timer display will flash “00”. The hob will beep for approximately one minute. • To switch off the beep and the flashing displays, touch any key. To cancel the timer •... -
Page 13: Key Lock
and hold the timer “+” or “-” keys to scroll through the duration quickly. • After approximately five seconds, the control LED stops flashing and the countdown will start. • At the end of the set time, the the timer display will flash “00” and the hob will beep for approximately one minute. - Page 14 in the relevant zone display after cooking until the zone is at a safe temperature to touch. In the event of a power cut, the residual heat indictors will illuminate after the power supply is restored. However, when there is no power supply to the hob the residual heat indicators will not work, so extra care must be taken.
-
Page 15: Efficient Use Of Your Hob
Efficient Use of Your Hob The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate zone depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 16: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 17: Troubleshooting
In the event of a fault with the hob, please advise CDA Customer Care of any fault code shown on the display Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY... - Page 18 The base diameter of the pan is Place a larger pan on the too small. cooking zone. The electronic system is Contact CDA Customer Care for “E” shows on the zone display. defective. advice. “Er03” shows on the zone One or more control keys are Clear any objects and clean display.
-
Page 19: Fitting The Hob
IMPORTANT: When correctly installed, your product meets all safety requirements laid down for this type of product. However, special care should be taken around the rear or the underneath of the appliance as these areas are not designed or intended to be touched and may contain sharp or rough edges that could cause injury. - Page 20 ventilation grille. • The furniture top rail should not be fitted to the unit. This allows the induction hob to exhaust air into the kitchen space. • The recommended ventilation sizes are for guidance only. If fitting a cooker hood above the hob: If a cooker hood is to be installed above the hob, the height of the hood above the hob must be at least 600mm (650mm is recommended) (Fig.
- Page 21 on the hob may not allow the hob to be used at the same time as a pyrolytic programme on the oven. • The hob is equipped with an anti-overheating safety device that can be activated if the hob is installed over an oven that is not sufficiently ventilated.
-
Page 22: How To Install The Hob
How to Install the Hob: Top rail removed to allow air to exit. Recommended 560mm x 6mm Overall dimensions of the hob: Width: 300 mm Depth: 510 mm Worktop cut-out dimensions: Width: 275 mm Depth: 490 mm 1. Make the required hole in the worktop. -
Page 23: Mains Electricity Connection
Mains Electricity Connection Warning! this appliance must be earthed We recommend that the appliance is connected by a FUSE SPUR OUTLET qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. This appliance is intended to be connected to fixed wiring and is USE A 13 AMP FUSE... - Page 24 230Vac, 50 Hz Total rated electrical consumption: 2.8 kW Any service call arising from incorrect installation may result in a charge. CDA and its representatives cannot be held responsible for any matters resulting from incorrect connection, or related to either...
- Page 25 the absense of an earth connection or a faulty earth connection.
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 Please contact our Customer Care Department for Service on the details below Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
