8.2.3 Patrol Settings
The camera can be set to patrol a group of preset points. For each patrol
group, the user can configure the preset point order, movement speed, and
viewing duration.
To create a patrol group:
a. Click on Add and enter a descriptive name in Description.
b. Add preset points to the patrol group by clicking the
preset point.
c. Use the arrow buttons to change the order of the preset positions by using
the Adjust the sequence of positions, and enter Movement Speed and
Viewing Duration for each preset point.
d. Click on Apply to save the patrol group.
e. Enable a patrol set by clicking on Start/Stop.
NOTE
1. A total of sixteen preset points can be assigned to a patrol group.
2. A total of four patrol groups can be assigned to a network camera.
