Page 1: Quick Installation Guide
12x PTZ Network Camera PZ-040 12x Series Quick Installation Guide... - Page 2 Read Before You Use 1. Power off the camera device immediately if it starts smoking or smells unusual. 2. Power off the camera device immediately if the camera is exposed to rain or liquid. 3. Do not set the camera device near any heat sources.
- Page 3 6. Do not set the camera device in any wet and humid environments. 7. Do not set the camera device on unsteady surfaces. 8. Do not attempt to dismantle the camera device. 9. Do not drop or hit the camera device. 10.
- Page 4 1. Check Package Contents a. PZ-040D/E 12x b. Product CD c. Mounting Kit d. I/O Cable e. Warranty Card f. Screw Bag g. Easy Installation Guide Alignment Sticker...
- Page 5 2. Device Description <Front View> 12 IR LEDs Light Sensor <I/O Connectors> Ethernet RJ45 10/100 Socket DC Power Connector General I/O Terminal Block Audio Out (Red) I/O Cable Microphone/Line In (Green) Video Out...
- Page 6 3. Hardware Installation 1. Connect the supplied I/O cable to the camera. 2. Install the Mounting Kit Soft Ceiling Mount Hard Ceiling Mount Step1. Choose a location on the wall or ceiling to place the camera. Attach the location sticker to the desired spot. Drill holes through the three location holes and cable hole on the sticker.
- Page 7 3. Loosen the screw on the rim of the metal plate but do not remove the screw completely. 4. Push all cables and connectors through the cable hole into the ceiling, and attach the PTZ camera to the metal plate. 5.
- Page 8 4. Camera Connection 1. Basic Connection (Without PoE) Connect the camera to a switch using a standard Ethernet cable. Connect the power adapter from the camera to a power outlet. Note: A DC12V 2A power adapter is required. 2. Power over Ethernet (PoE) Connection The PZ-040D/E is High Power PoE compliant, so there are two options for connecting the camera to a power and Ethernet source.
- Page 9 Use a single Ethernet cable to connect the camera to the High Power PoE-enabled switch. Note: The PoE switch must be able to provide IEEE802.3at High Power PoE. It is recommended that a Brickcom PS-7242-AT 24 port high power PoE switch be used. B. If using a non-PoE switch 1.
- Page 10 1. Insert the Installation CD into the CD-ROM driver. Run Auto-Run Tool directly from the CD-ROM to start the installation. When installing the Brickcom software kit for the first time, select a desired language for the interface. The available languages are listed in the scroll box. Click “Install”...
- Page 11 2. Select either EasyConfig or PC-NVR Standard to launch. If the PC-NVR program is launched, please refer to the PC-NVR user manual.
- Page 12 If Custom Setup type was used in software installation and an EasyConfig icon was not installed on the desktop, the program should be installed under C:\Program Files\Brickcom\EasyConfig unless the program was saved to a preferred directory. 1. Click <Start> to continue. The program will automatically search for the network camera in the intranet.
- Page 14 2. Select either Simple Mode or Professional Mode to obtain the Network Camera’s IP setting. If Simple Mode is selected, EasyConfig will set up the connection automatically. If Professional Mode is selected, the user will need to configure the IP settings manually. 3.
- Page 15 For configuring the IP address settings, select either <Settings remain the same>, <Automatically obtain an IP Address (DHCP)> or <Set IP Address configuration manually>. The DHCP setting is recommended. To set the IP address manually, please refer to the product user manual.
- Page 16 a. If <Set IP Address configuration manually> is selected, the following pages will be displayed.
- Page 17 If desired, click <Skip> to skip this setting. EasyLink is a unique Brickcom function which allows users to assign a unique EasyLink name to their network camera’s IP address. There is no need to configure the router to open up ports or remember hard-to-memorize addresses.
- Page 18 connected IP camera. To run the PC-NVR program, please refer to the PC-NVR user manual for more information.
