Hardware overview
180° mark
(top of image)
LED indicators
Lens holder
Control button
Optic mount
Optic holder
Use screws here to mount camera
Top cover tool
Netzwerkkabel cable (0.5m/1.6ft.)
Lens tool
Lens tool
(AXIS M3114-R M12 2MM)
Black rubber side (for focus adjustment)
Transparent side
(for image adjustment)
Lens tool for adjusting image
Lens tool for adjusting focus
