Delta Audio Controller Status Messages

Controller Status Messages
ERR
ACK
MVERx
MCFr,s,z
FNICxx
FSICx,a,v,p,d
MVLr,v
MBSr,b
MTRr,t
MSCr,s
Delta Series Audio Controllers
Error
Acknowledge Status
Firmware Version Status, where 'x' is the current firmware version (4 digits)
Configuration Status, where:
• 'r' is the number of rooms connected, (2-6)
• 's' is the number of sources connected, (4)
• 'z' is the number of groups available, (r/2)
Num IIC Devices Status, where 'xx' denotes the number of IIC devices available in the
MRC
IIC Device Status, where:
'x' is the IIC device index, valid values range from 1 to the number of IIC devices as
denoted in the 'Num IIC Devices Status'
• 'a' is the device ID (3 digits)
• 'v' is the version (4 digits)
• 'p' is the product ID (4 digits)
• 'd' is a descriptive string for the device, the string is of variable length
Volume Status, where:
• 'r' denotes the room, (1-64)
• 'v' denotes the volume setting, valid values are:
101: Mute
0...100: 0...-100 dB
Bass Status, where:
• 'r' denotes the room, (1-64)
• 'b' denotes the bass level, valid values are:
0: level
1...10: -10...-1 dB
11...20: 1...10 dB
Treble Status, where:
• 'r' denotes the room, (1-64)
• 't' denotes the bass level, valid values are:
0: level
1...10: -10...-1 dB
11...20: 1...10 dB
Source Status, where:
• 'r' denotes the room, (1-64)
• 's' denotes the source, valid values are:
0: no source selected
1-8: for sources 1 to 8 selected
RS-232 Control Commands / Messages
