RS-232 Controller Command Messages (Cont.)
MSGLs,i,o
MGSTr
MSSTs,x
MCMDs,x
MSBLr,x
MGBLr
MDRG
MGRSs
MSPSs,n,p
Delta Series Audio Controllers
Set Gain Level, where:
• 's' is the desired source
• 'i' is the desired input gain, valid values are:
0: 0 dB
1: -3 dB
2: -6 dB
3: -9 dB
4: -12 dB
• 'o' is the desired output gain, valid values are:
0: 0 dB
1: +3 dB
2: +6 dB
3: +9 dB
4: + 12 dB
5: + 15 dB
6: + 18 dB
Get General Status, where:
'r' is the desired room, (1-64)
Set Source State, where:
• 's' is the desired source, (1-8)
• 'x' is the desired state, valid values are:
2: Pause
1: On
0: Off
Send Source Command, where:
• 's' is the desired source, (1-8)
• 'x' is the desired command index, valid values depend on the
source type.
• 'y' is the play option for the Sirius internal tuner only. Other
source types will ignore. (1=play, 0=browse)
Set Room Balance, where:
• 'r' is the desired room, (1-64)
• 'x' is the balance value, valid values are:
0: balanced evenly
1...10: Full Left...10% Left
11...20: 10% Right... Full Right
Get Room Balance, where:
'r' is the desired room, (1-64)
Dissolve all Room Groupings
Get the Rooms currently listening to a source, where:
's' is the desired source, (1-8)
Set the preset, where:
• 's' is the desired source, (1-8)
• 'n' is the desired preset, (1-10)
• 'p' is the direct tuning string; it can be from 0 to 7 characters long
and is translated as specified in the 'Send Source Direct Data'
command: Zero length data will clear the preset
RS-232 Control Commands / Messages
Gain Status
- or -
ERR
General Status
- or -
ERR
Source State Status
- or -
ERR
ACK
- or -
Sirius Channel Number
(Sirius Type Only)
- or -
ERR
Balance Status
- or -
ERR
Balance Status
- or -
ERR
ACK
- or -
ERR
Source Grouping Status
- or -
ERR
Preset Status
- or -
ERR
65
