Delta Series Product Specifications (Cont.)
• LCD Display Screen
Rear Panel Components:
• Power Switch & Receptacle
• AM/FM Antenna Inputs
• IR Outputs (4)
• Zone Outputs (up to 6)
• RJ 45 Port
• RS-232 and USB Ports
• Source Inputs (up to 4)
• Preamp Outputs
Dimensions (HWD) - including feet and
rear connectors:
Weight:

Tuner Antenna Details

2
The TA-MOD tuner automatically becomes source #1 when installed into the Delta Controller
The TA-MOD tuner requires a 75 Ohm F-Type connection to receive FM stations.
The TA-MOD tuner requires an AM antenna loop to receive AM stations.
Displays information necessary during the programming steps and
afterward is the display to indicate information about the source input
and zone activity.
The master power switch will remain in the ON position normally.
Connections for the AM and FM Antennas.
Four 3.5mm IR Emitter Output Jacks.
Note: Be sure to connect the emitter to the same numbered port as
the corresponding source input.
Connections for zone outputs that connect to the keypads.
Ethernet Port for future expansion
For firmware upgrades and interface with NetLinx control systems.
RCA connections for 2-channel audio input from up to 4 external
sources (unless an AM/FM tuner board is present, which internally
takes up the Source #1 location - then it's 3 additional sources).
RCA outputs to run an external amplifier. This is only available for
Zone output #1.
• 3 1/16" x 17" x 13 1/2"
• 7.68cm x 43.18cm x 33.52cm
24.05 lbs (10.91 kg)
