WARNING:
If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of
life.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an aftermarket permanently
located, manufactured home (USA only) or mobile home, where
not prohibited by local codes.
This appliance is only for use with the type(s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
Owner's Manual
© Copyright 2009, T.I.
•
$10.00
100-01209_000
21 TRV
GreenSmart™
Fireplace
• Operation
• Maintenance
Tested and Listed by
OMNI-Test Laboratories, Inc.
Portland, Oregon
Report # 028-F-59c-5
ANSI Z21.88a-2003
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
4090403
Mukilteo, WA 98275
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries 21 TRV GreenSmart
Summary of Contents for Travis Industries 21 TRV GreenSmart
- Page 1 21 TRV GreenSmart™ Fireplace • Operation • Maintenance Tested and Listed by OMNI-Test Laboratories, Inc. Portland, Oregon Report # 028-F-59c-5 ANSI Z21.88a-2003 • WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Introduction
Introduction Introduction We welcome you as a new owner of a 21 TRV GreenSmart gas fireplace. This manual details operation and maintenance of this fireplace. Please familiarize yourself with the Owner's Manual before operating your heater and save the manual for future reference. -
Page 3: Table Of Contents
Heating Specifications Natural Gas Propane Approximate Heating Capacity (in square feet)* Up to 650 Up to 650 Maximum BTU Input Per Hour 16,500 16,500 Heating capacity will vary with floor plan, insulation, and outside temperature. 4090403 © Travis Industries 100-01209_000... -
Page 4: Safety Precautions
Immediately call a qualified vicinity of this heater. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4090403 © Travis Industries 100-01209_000... - Page 5 If the fiber logs become damaged, replace with Travis Industries log set. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...
-
Page 6: Operation
This switch turns the rear burner on and off. AA Battery Holder This holder contains 4 AA batteries that allow the fireplace to operate during power outages. Main Burner This switch turns the fireplace burners on and off. 4090403 © Travis Industries 100-01209_000... -
Page 7: Starting The Fireplace For The First Time
The rear portion of the burner may be shut off to lower the heat output and flame size from the burner (this is called the comfort control). Use the comfort control switch to adjust this as desired. COMFORT CONTROL 4090403 © Travis Industries 100-01209_000... -
Page 8: Adjusting The Flame Height
Accent Light This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. HIGH ACCENT LIGHT HIGH 4090403 © Travis Industries 100-01209_000... -
Page 9: Adjusting The Optional Blower Speed
Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. CONTINUOUS PILOT GREEN SMART PILOT 4090403 © Travis Industries 100-01209_000... -
Page 10: Normal Operating Sounds
This appliance has several areas that reach high temperatures. Dust or other particles on these areas may burn and create an odor. This is normal during start-up. You may notice the smell is more acute if the appliance was left idle for a long period. 4090403 © Travis Industries 100-01209_000... -
Page 11: Maintenance
Battery Holder for Control Panel Lights Swing the access door down to access the area below the firebox. Swing the Battery concealment cover Holder down to expose the controls. AA Battery Tray 4090403 © Travis Industries 100-01209_000... -
Page 12: Accent Light Replacement
If the pilot or main burners do not burn correctly, contact your dealer for service. Monitor blower operation. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or deterioration is found near the vent termination. 4090403 © Travis Industries 100-01209_000... -
Page 13: Face Installation And Removal
PLATED SURFACES: Make sure the plated surfaces are clean before starting the fireplace. Any marks left on plated surfaces may become etched in place. Clean plated surfaces with denatured alcohol and a soft cloth. 4090403 © Travis Industries 100-01209_000... -
Page 14: Glass Frame Removal And Installation
Insert the tabs on the glass frame into the slots on the glass frame brackets (attached to the fireplace). Attach the two glass latches. NOTE: Make sure the glass frame is all the way in place - it should be flush with the front of the fireplace when installed. 4090403 © Travis Industries 100-01209_000... - Page 15 Top of Firebox Glass Frame Anchor Note how the washer on the latch fits behind the flange on the glass frame anchor. Once fully inserted, turn the latch until it is upright. 4090403 © Travis Industries 100-01209_000...
-
Page 16: Log Set Installation
The bottom edge of the log should be located behind the burner ports (see the illustration below). CROSS-SECTIONAL VIEW Rear Log Burner Make sure the ledge on the burner lines up with stepped-down portion of the rear log. 4090403 © Travis Industries 100-01209_000... - Page 17 The right twig rests on the burner and leans against the indent on the right log. Install the twig as shown below. The bottom of the twig is placed one inch to the right of the center screw on the burner. 4090403 © Travis Industries 100-01209_000...
- Page 18 Log Installation Overview Correct view of complete log installation. Place embers in the firebox corners and along the front edge of the burner. Do not place embers over burner holes or allow the embers to block airflow. 4090403 © Travis Industries 100-01209_000...
-
Page 19: Troubleshooting Table
Replace the AA batteries (see page 11) Comfort Control Does not Work The logs or coals are placed incorrectly See "Log Set Installation" Thin Layer of Soot Improper air shutter adjustment Adjust Air Shutter - contact your dealer Covers the Glass 4090403 © Travis Industries 100-01209_000... -
Page 20: Wiring Diagram
IPI / CPI Black Blue White White Black CONTINUOUS PILOT BATTERY COMFORT MAIN BURNER TRAY GREENSMART CONTROL PILOT Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4090403 © Travis Industries 100-01209_000... -
Page 21: Greensmart Wiring Diagram
INTERMITTENT Power In 110V OUT AUX OUT PILOT Accent Thermodisk Light (s) Optional Blower(s) Accent Light Rheostat Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4090403 © Travis Industries 100-01209_000... -
Page 22: Replacement Parts List
Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 23: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your appliance. -
Page 24: Optional Equipment
Blower The optional blower helps transfer heat to your home. Liners There are several styles of decorative liners that fit inside the firebox and enhance the area behind the flames. 4090403 © Travis Industries 100-01209_000... - Page 25 Optional Equipment 4090403 © Travis Industries 100-01209_000...
-
Page 26: Index Index
Safety Precautions .............. 4 Starting the Fireplace for the First Time ......7 Troubleshooting Table ............19 Turning the Fireplace On and Off ........7 Warranty ................27 Wiring Diagram ..............20 Yearly Service Procedure ........... 12 4090403 © Travis Industries 100-01209_000...
