Packing List
•
Rear Fireback
•
(2) Side Firebacks
•
Floor Fireback
Installation
WARNING
Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
NOTE:
The firebacks are shipped in vinyl to prevent marring the surface of the stainless steel. Remove
the vinyl prior to installation. Wear clean gloves when installing the firebacks to prevent
fingerprints on the surface (or use a rag or paper towel to handle the firebacks).
1
Remove the glass frame and logs (see the installation manual for details).
2
Remove the grate (replace after fireback installation). Remove and discard the hearth plate.
1/4" Nutdriver
Remove the grate
(replace after fireback installation).
Remove the screw and bracket.
Page 1 of 2
564 SS Stainless Steel Fireback Installation
SKU # 96100180
Remove and discard
the hearth plate
7/25/07
Travis Industries, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries Space Saver GreenSmart 2 564
Summary of Contents for Travis Industries Space Saver GreenSmart 2 564
- Page 1 Remove the grate (replace after fireback installation). Remove and discard the hearth plate. 1/4" Nutdriver Remove the grate (replace after fireback installation). Remove the screw and bracket. Remove and discard the hearth plate Page 1 of 2 7/25/07 Travis Industries, Inc.
- Page 2 Any cleaning may lead to unequal coloring. If soot forms on the fireback, we recommend brushing it off with a soft cloth or brush. Restore the fireplace to the correct configuration. Page 2 of 2 7/25/07 Travis Industries, Inc.
