WARNING: If the information in this manual is
not followed exactly, fire or explosion may result
causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
Installer: Please leave this manual with the appliance owner for future reference
For use with natural gas or propane*
U
O
M
*Conversion kit required for Propane use
7116 Beatty Dr
Mission, BC V2V 6B4
Canada
NORTHFIRE 3400
3400-DVTR20N-2
SN 8605 and up
Direct Vent Top/Rear
Gas Fireplace
I
SERS'
NSTALLATION
PERATION AND
AINTENANCE
This
appliance
may
aftermarket permanently located, manufactured
home (USA only) or mobile home, where not
prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases,
unless a certified kit is used.
M
ANUAL
be
installed
in
an
200-1913
JUNE 2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Archgard NORTHFIRE 3400 3400-DVTR20N-2 SN 8605
Summary of Contents for Archgard NORTHFIRE 3400 3400-DVTR20N-2 SN 8605
- Page 1 NORTHFIRE 3400 3400-DVTR20N-2 SN 8605 and up Direct Vent Top/Rear Gas Fireplace For use with natural gas or propane* WARNING: If the information in this manual is SERS’ NSTALLATION not followed exactly, fire or explosion may result causing property damage, personal injury or loss PERATION AND of life.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction General Information Appliance Description and Dimensions Framing Dimensions Clearance to Combustibles Possible Fireplace Locations Venting Instructions 10-15 Gas Connection Glass Door Removal Log Placement Fan and Valve Diagrams Initial Start-Up Maintenance Troubleshooting 23-24 Servicing 25-29 Replacement Parts List Top/Rear Vent Conversion Instructions Warranty Warranty Registration Card... -
Page 4: Introduction
Northfire 3400 INTRODUCTION Thank you for purchasing the Northfire 3400 Direct Vent Built-in Gas Fireplace Heater. The Northfire 3400 is one of the most advanced gas fireplace heaters on the market. It is designed using the latest technology and manufactured to the highest quality. Some of the many features are: Small Size The Northfire 3400 is compact enough to fit into almost any size... -
Page 5: General Information
US and Canadian gas appliance standards. - ANSI Z21.88b-2002 / CSA 2.33b-2002, Vented Gas Fireplace Heaters and - CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes. Please contact Archgard Industries Ltd., if you have any questions regarding the certification of this appliance. INSTALLATION CODES This appliance must be installed by a qualified gas appliance installer. -
Page 6: Appliance Description And Dimensions
Northfire 3400 APPLIANCE DESCRIPTION & DIMENSIONS FRONT VIEW TOP LOUVRES GLASS DOOR CONVECTION FAN SPEED CONTROL GAS VALVE APPLIANCE DIMENSIONS ¾” 1½” 34 5/8 ” 23 ½” 23 ½” FRONT VIEW 3½” 35 ¾” 5 ¼” TOP VIEW SIDE VIEW * Except for the vent connector locations, the rear vented and top vented units have the same physical dimensions. -
Page 7: Framing Dimensions
Northfire 3400 FRAMING DIMENSIONS FRAMING DIMENSIONS 16” *31” 34 3/4 ” * If more rigidity is required, a stud may be added to the back of the top nailing flange after the fireplace is installed. TERMINATION FRAMING 16” 34 3/4” 11”... -
Page 8: Clearance To Combustibles
Northfire 3400 CLEARANCE TO COMBUSTIBLES PRECAUTIONS This appliance must be installed by a qualified gas installer and the installation must conform to the installation codes. Provide adequate clearance around air openings of the appliance. Never obstruct front openings. Provide adequate clearances for proper operation and servicing of the appliance. This appliance must be properly connected to a venting system. -
Page 9: Possible Fireplace Locations
Northfire 3400 POSSIBLE FIREPLACE LOCATIONS LOCATING GAS FIREPLACE This appliance must be installed in a location that is free of plumbing, electrical wiring and heating or air conditioning ducts. Select a location that is accessible for venting. See APPENDIX A. ALLOWABLE TERMINATION LOCATIONS. -
Page 10: Venting Instructions
7. Maintain at least an upward slope of 1” for every 1 ft of horizontal run on the rear vented models. 8. Terminate the vent with a vent termination supplied by Archgard Industries Ltd. 9. Support horizontal running vents every 3 ft to prevent it from sagging. - Page 11 Northfire 3400 Follow the venting instructions as strictly as possible to obtain the best performance from the appliance. **Top/Rear Conversion Instructions Pg. 30** VENTING INSTRUCTIONS Top/Rear Vent Units Maintain a minimum of 1” clearance to combus- tibles on sides and bottom and 2” from top sur- face of the vent.
- Page 12 Northfire 3400 VENTING INSTRUCTIONS RESTRICTOR INSTALLATION (See pg. 14)
- Page 13 Northfire 3400 VENTING INSTRUCTIONS...
- Page 14 Archgard System In the Archgard system the restrictors are placed on the exhaust outlet on the appliance. Simpson Duravent With Simpson Duravent locate the restrictor in the exhaust section fitting into the formed lip.
- Page 15 Northfire 3400 VENTING INSTRUCTIONS Cont... The rigid vent systems use twist lock connections. The adaptor attached to the unit connects to the approved venting system. Assemble the vent system using the desired combination to sections and fittings required for your particular installation. While you are assembling the pipe bear in mind the best visual appearance. Seams should be aligned and hidden as much as possible.
-
Page 16: Gas Connection
Northfire 3400 GAS CONNECTION INSTRUCTIONS GAS CONNECTIONS Before connecting the appliance to the gas supply line, double check that the appliance you have purchased is designed for the gas type you are using. The gas type markings are located on the certification label and also on the appliance‟s gas valve. Provide adequate clearance for proper installation and checking of the gas connections. -
Page 17: Glass Door Removal
Place the door at a safe location where it cannot be scratched or damaged. If the glass door is damaged, it must be replaced with another glass door certified with this appliance only. Replacement glass doors are available through your Archgard dealer See Replacement Parts page 29 Replacing the Glass Door Check the condition of the glass and the gasket before installing door. -
Page 18: Log Placement
Northfire 3400 LOG PLACEMENT INSTRUCTIONS PIN NUMBERS AND LOCATIONS PIN #5 PIN #6 PIN #4 PIN #7 PIN #3 PIN #8 PIN #2 PIN #9 PIN #1 PIN #10 PLACEMENT OF LOGSET Step 1: Place rear right log on pin numbers 7 and 8 with Step 2: Place rear left log on pin numbers 3 and 4 with the the left side of the log resting on the pilot shield so as to right side of the log resting on the rear right log so as to al-... - Page 19 Northfire 3400 Step 3: Place left front log on pin numbers 1 and 2 as Step 4: Place right front log on pin numbers 9 and 10 as shown. shown. Step 5: Place the center log on pin numbers 5 and 6 with Step 6: Place the coals on top of the burner so as not to the larger branch facing forward between the front left and block any of the burner ports or the secondary air flow...
-
Page 20: Fan And Valve Diagrams
Northfire 3400 FAN & VALVE WIRING DIAGRAM/INSTRUCTIONS ELECTRICAL CONNECTIONS (for optional convection fan kit 999-DV-FK only) Install the fan first. Remove the lower louvers and gently place the bottom front lip of the blower mounting bracket into the opening. Slide the blower assembly into the bottom of the fireplace. -
Page 21: Initial Start-Up
Northfire 3400 INITIAL START-UP INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which must be lighted by hand. When lighting the pilot, follow these instructions exactly. BEFORE LIGHTING smell all around the appliance area for gas. -
Page 22: Maintenance
Northfire 3400 MAINTENANCE CAUTION : Only conduct maintenance on a cold appliance. CLEANING THE APPLIANCE The exterior painted surfaces, glass and gold trims may be cleaned with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive cleaner. Regularly: Clean and remove any lint accumulations or debris from the grills and in any combustion and convection air passageways. -
Page 23: Troubleshooting
Northfire 3400 TROUBLESHOOTING Please check to make sure the instructions are followed exactly before attempting troubleshooting of the appliance. WARNING: Troubleshooting and servicing of gas and electrical devices of the appliance should only be conducted by a qualified service technician. SYMPTOM ACTION Pilot will not light after pressing the... - Page 24 Northfire 3400 TROUBLE SHOOTING Cont... SYMPTOM ACTION The main burner does not turn on with 3. Check to make sure the thermostat is set high enough to turn on the appliance. the pilot lit. Cont... 4. Check that the remote switch or the thermostat is turned on. 5.
- Page 25 SERVICING SERVICING UNDER WARRANTY Before servicing, read the terms and conditions of the Archgard warranty at the back of the manual. Contact the Archgard authorized dealer which you have purchased the appliance from and provide him with details of the problem and the installation information which the installer has fill out at the back of the manual.
- Page 26 Northfire 3400 SERVICING Cont... CHANGING MAIN BURNER ORIFICE Remove the glass door, log set and brick panels (if used) Remove the burner by removing the screws holding the burner and cover plate Use two wrenches to loosen and remove the cap orifice. Change the orifice.
- Page 27 WRENCH (HERE) the other side of the body and retighten. Call your local Authorized Archgard Dealer to purchase the correct fuel conversion kit for your gas appliance. IF YOUR GLASS BREAKS In the event your glass cracks or breaks, it must be replaced by the exact same size and mate- rial.
-
Page 28: Servicing
Northfire 3400 SERVICING Cont... REPLACING VALVE PLATE ASSEMBLY Disconnect electricity to the appliance. (If equipped with Optional Fan Kit) Remove the glass door and the logs. See glass door instructions. Remove the burner tray by loosening and removing the two mounting screws located on the burner cover and burner. - Page 29 Northfire 3400 SERVICING Cont... Caution: Do not service appliance while it is operating or still hot. Cleaning the Appliance: The exterior surfaces and glass may be cleaned with a soft, non- abrasive, cloth and water or a suitable mild, non-abrasive cleaner. Regularly -Clean and remove any lint accumulations or debris from the grills and in any combustion and convection air passage ways.
-
Page 30: Replacement Parts List
Northfire 3400 REPLACEMENT PARTS LIST PART # ITEM DESCRIPTION UNIT 200-1913 OWNERS MANUAL, NORTHFIRE 3400-DVTR20N-2 301-0068 ORIFICE CAP, DRILL TO #45 (NATURAL GAS) 301-0068 ORIFICE CAP, DRILL TO #55 (PROPANE GAS) 307-0016 GLASS, CERAMIC 16.150 X 28.843 305-0013 FAN SPEED CONTROL (RHEOSTAT) (FOR OPTIONAL FAN KIT FK-36/38) 305-0021 FAN THERMODISC 110 DEG, FAN SENSOR (FOR OPTIONAL FAN KIT FK-36/38) RF-305-0024... -
Page 31: Top/Rear Vent Conversion Instructions
Northfire 3400 TOP/REAR VENT CONVERSION The appliance is easily converted from top vent to rear vent. The steps for converting are as follows: 1. Remove the vent outer shell cover (#1). 2. Remove the outer collar assembly (#2). 3. Remove the exhaust collar assembly (#3). 4. -
Page 32: Warranty
Problem Description ❖ NOTE: Warranty may be void if work is carried out by an unqualified person (s). Only original Archgard parts may be used. Please consult your Archgard dealer or representative if in doubt about a replacement part (s). -
Page 33: Warranty Registration Card
Postage WARRANTY REGISTRATION ARCHGARD INDUSTRIES LTD. 7116 BEATTY DRIVE MISSION, B.C. CANADA V2V 6B4 FOLD DOWN AT LINE FOLD DOWN AT LINE & TAPE CLOSED 3400-DVTR20N-2 Model # : Serial #: Date Installed: Name & Address: City/State PC/Zip Phone: ( ______ ) Dealer's Name &... - Page 35 Archgard Industries Ltd. 7116 Beatty Drive Mission, B.C. V2V 6B4 Canada Website: www.archgard.com...
