Archgard Pele 345-DVTE31LN-1 Installation, Operation And Maintenance Manual

Archgard Pele 345-DVTE31LN-1 Installation, Operation And Maintenance Manual

Gas fired direct vent fireplace
Hide thumbs Also See for Pele 345-DVTE31LN-1:
Table of Contents

Advertisement

WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in
serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance
Do not touch any electrical switch; do not use any
phone in your building
Leave the building immediately
Immediately call your gas supplier from a neighbor's
phone. Follow the gas suppliers instructions
If you can not reach your gas supplier, call the fire
department
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
English and French Installation Manuals available through your
local dealer or visit our website at: www.archgard.com
Les manuels d'installation en anglais et en français son
disponibles chez votre détaillant local ou en visitant notre site
web: www.archgard.com
INSTALLER:
LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER:
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
ARCHGARD FIREPLACE PRODUCTS
7116 Beatty Drive
Mission, BC V2V 6B4 Canada
INSTALLATION, OPERATION, AND
MAINTENANCE MANUAL
Pele 345
MODEL: 345-DVTE31LN-1
GAS FIRED DIRECT VENT FIREPLACE
S/N 340000 AND UP
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only) or
mobile home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
Gas Fireplace Energy Efficiency Rating
67.98%
Based on CSA P.4.1-15
200-3345-01
July 8, 2020
