GE Monogram ZV30RS Technical Service Manual page 26

ZV30, ZV36, and ZV48 - RSF1SS Models
VIEW CATALOG
NUMBER NUMBER
13 WB02X10872
19 WB27X10669
23 WB02X10897
31 WB08X10028
32 WB08X10030
58 WB07X10660
84 WB20X10026
87 WB02X10871
103 WB38X10069
105 WB08X10032
117 WB08X10033
209 WB61X10004
225 WB01X10070
225 WB02X10832
234 WB24X10110
236 WB03X10163
291 WB07X10608
315 WB02X10899
512 WB24X10111
539 WB02X10900
565 WB08X10029
573 WB08X10031
574 WB01X10211
999 49-80152
999 49-80150-1
DESCRIPTION
JUNCTION BOX COVER
CAPACITOR
FILTER, BAFFLE
120V 50W HALOGEN BULB
LAMPHOLDER
SHELF
TRANSFORMER
DUCT TRANSITION W/DAMPER
BLOWER ASSEMBLY
LAMPHOLDER SUPPORT
INDICATOR LIGHT
BACK SPLASH
CLIP LOGO
MONOGRAM LOGO
SWITCH, MOTOR/LAMP
KNOB ASSEMBLY
HEAT LAMP PANEL 30"
GREASE TRAY 30"
HEAT-LAMP ROCKER SWITCH
UTENSIL ROD-TAPER 30"
120V 175W INFRARED LAMP
BEZEL LAMP
HARDWARE BAG
USE & CARE
INSTALLATION
