Note: Make sure the pin on the rotary switch is
aligned with the hole in the panel before installing
the nut.
Hole
Pin
Autotransformer
Removal and Replacement
1. Remove the
Heat Lamp Panel
2. Remove the light switch control knob. (See
.)
Rotary Switch
3. Remove the fan switch control knob. (See
.)
Rotary Switch
4. Remove four screws from the
autotransformer.
5. Label and disconnect seven terminal lugs
from the autotransformer.
Terminal Lugs
Removal and Replacement
1. Remove the
2. Reach behind the hood and disconnect the 2
3. Pull the indicator light socket from the red
.
Screw
– 15 –
Fan Motor Indicator Light
Heat Lamp Panel
wires from the indicator light socket.
indicator cap.
.
