GE Monogram ZV30RS Technical Service Manual page 14

Surface Light Sockets
Removal and Replacement
1. Remove the
Heat Lamp Panel
2. Remove the surface lights.
3. Press the socket clamps in and pull the
socket from the surface light panel.
4. Loosen the 2 wire retaining screws and
remove the wires from the overhead light
socket.
Rotary Switch
Removal and Replacement
. Note: The procedure to remove both the fan
rotary switch and the light rotary switch are
identical.
1. Remove the
2. Pull the control knob off the rotary switch.
3. Remove the nut from the front of the rotary
4. Reach behind the hood and pull the rotary
5. Label and disconnect the 7 terminal lugs from
6. Label and disconnect seven terminal lugs
– 14 –
Heat Lamp Panel
switch.
Nut
switch out to access the electrical
connectors.
the rotary switch and remove the rotary
switch.
Connectors
from the rotary switch.
.
