Components Locator Views

Rear View (Non-Inverter model shown)
Main Control Board

3-Way Valve

Condenser Fan

Compressor
Condenser
Dryer
Water Valve
Jumper Tube
Rear View (Inverter model shown
with drain tube and selected wiring
Compressor
removed for clearer view.)
Inverter
(Continued next page)
