GE Profile PSF26PGWBB Technical Service Manual page 27

19. Press inward on the 2 tabs and release the
auger motor assembly wire harness receptacle
from the evaporator fan plenum.
20. Remove the 4 hex-head screws that hold the
evaporator fan plenum in place (Fig. 1 and
Fig. 2).
Top Hex-head Screws
Fig. 1
Note: The bottom hex-head screws are hidden
under the bottom of the evaporator fan plenum.
Bottom Hex-head Screws
Fig. 2
21. Unclip the evaporator thermistor and ground
wires from the evaporator.
22. Remove the two ¼-in. hex-head screws from
the fan bracket.
Thermistor
23. Peel back the tape then slide out the wiring
grommets from the fan bracket.
24. Remove the fan bracket.
– 27 –
Ground Wires
Grommet
(1 of 2)
