Icom iF34GT Instruction Manual page 12

2
PANEL DESCRIPTION
PRIORITY CHANNEL KEYS
➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] to rewrite the Prio A
channel.
MR-CH 1/2/3/4 KEYS
Push to select the memory channels 1 to 4 directly.
LOCK KEY
➥ Push and hold for 1 sec. to electronically lock all program-
mable keys except the following:
[Call] (incl. Call A and Call B), [Moni(Audi)] and
[Emergency].
➥ Push and hold for 1 sec. again to turn the lock function
OFF.
OUTPUT POWER SELECTION KEY
Push to select the transmit output power temporarily or per-
manently, depending on the pre-setting.
• Ask your dealer for the output power level for each selection.
C.TONE CHANNEL ENTER KEY
Push to select the continuous tone channel using [CH Up]/
[CH Down] to change the tone frequency/code setting after
pushing this key for permanent operation.
TALK AROUND KEY
Push to turn the talk around function ON and OFF.
• The talk around function equalizes the transmit frequency to the
receive frequency for transceiver-to-transceiver communication.
8
MONITOR KEY
➥ Push to mute and release the CTCSS (DTCS) or 2-tone
squelch mute. Open any squelch/deactivate any mute
while pushing and holding this key. (LMR operation only)
➥ Activates one of (or two of) the following functions on
each channel independently: (PMR or BIIS PMR opera-
tion only)
• Push and hold to un-mute the channel (audio is emitted;
'Audible' condition).
• Push to mute the channel (sets to 'Inaudible' only).
• Push to un-mute the channel (sets to 'Audible' only).
• Push after the communication is finished to send a 'reset
code'.
NOTE: The un-mute condition ('Audible' condition) may
automatically return to the mute condition ('Inaudible'
condition) after a specified period.
WIDE/NARROW KEY
Push to toggle the IF bandwidth between wide and narrow.
• The wide passband width can be selected from 25.0 or 20.0 kHz
using the CS-F33G
cloning software
tion only) Ask your Dealer for details.
DTMF AUTODIAL KEY
➥ Push to enter the DTMF channel selection mode.
Then select the desired DTMF channel using [CH Up]/
[CH Down] keys.
➥ After selecting the desired DTMF channel, push this key
to transmit the DTMF code.
. (PMR or BIIS PMR opera-
