Page 1: Battery Charger
BATTERY CHARGER BATTERY CHARGER USER'S MANUAL USER'S MANUAL... - Page 2 (THIS PAGE WAS INTENTIONALLY LEFT BLANK)
-
Page 3: Table Of Contents
Table of Contents · 1. Introduction..................4 · RESPONSIBILITY DISCLAIMER................ 4 · 2. Safety instructions and warnings............5 · GENERAL......................5 · SHOCK PREVENTION..................5 · BURN AND BODILY INJURY PREVENTION............6 · FIRE AND EXPLOSION PREVENTION.............. 6 · MEDICAL AND FIRST AID TREATMENT............6 ·... -
Page 4: Introduction
RESPONSIBILITY DISCLAIMER The manufacturer of the Energic plus RE battery charger will not be responsible for damages and/or injuries caused by the charger in these situations: The charger is not installed properly by a qualified electrician;... -
Page 5: Safety Instructions And Warnings
Battery Charger RE User's Manual Safety instructions and warnings GENERAL Battery chargers can cause injury or death, or damage to other equipment or property, if the user does not strictly observe all safety rules and take precautionary actions. Safe practices must be learned through study and training before using this equipment. Only qualified personnel should install, use, or service this battery charger. -
Page 6: Burn And Bodily Injury Prevention
Battery Charger RE User's Manual BURN AND BODILY INJURY PREVENTION The battery produces very high currents when short circuited, and will burn the skin severely if in contact with any metal conductor that is carrying this current. Do not permit rings on fingers to come in contact with battery terminals or the cell connectors on top of the battery. -
Page 7: Description
Battery Charger RE User's Manual Description Energic plus RE battery chargers have been designed to charge Pb batteries. These units convert the AC input voltage to a DC voltage at the correct level, in order to charge the battery cells. -
Page 8: Installation
Battery Charger RE User's Manual 4. Installation The charger is marked with a technical label, containing the following data: Model; • Serial number (S/N); • Weight (kg); • Input voltages (V); • Maximum input current (A); • Maximum input power (KVA); •... -
Page 9: Internal View Of The Charger, Cabinet S
Battery Charger RE User's Manual CAUTION ! To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. CAUTION ! Allow adeguate air circolation to prevent internal heat buildup. Do not place the unit near materials that may block the ventilation slots. Do not install the unit near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, excessive dust, mechanical vibration or shock. -
Page 10: Internal View Of The Charger, Cabinet A
Battery Charger RE User's Manual INTERNAL VIEW OF THE CHARGER – CABINET A INTERNAL VIEW OF THE CHARGER – CABINET B Page 10 of 24 OWM-040906-RE Version: 02-AB... -
Page 11: Internal View Of The Charger, Cabinet C
Battery Charger RE User's Manual INTERNAL VIEW OF THE CHARGER – CABINET C ELECTRICAL INSTALLATION OF THE CHARGER Check the efficiency of earth circuitry (yellow/green wire); • Connect the charger to the mains using an adeguate plugs, with pushbutton and fuses; •... -
Page 12: Ac Input Voltage Adjustment - Cabinets S, A, B
Battery Charger RE User's Manual AC INPUT VOLTAGE ADJUSTMENT – CABINETS S, A, B CAUTION These settings can be done by qualified personnel only. For more information please contact the manifacturer. PROCEDURE: Disconnect the charger from main supply and • battery;... -
Page 13: Ac Input Voltage Adjustment - Cabinet C
Battery Charger RE User's Manual AC INPUT VOLTAGE ADJUSTMENT – CABINET C CAUTION These settings can be done by qualified personnel only. For more information please contact the manifacturer. PROCEDURE: Disconnect the charger from main supply and • battery; Open the cabinet; •... -
Page 14: How To Use The Charger [Cabinets S, A, B]
How to use the charger [Cabinets S, A, B] WARNING ! ENERGIC Plus RE chargers are programmed to do a complete cycle of charge, however it’s recommended to survey the operations when the battery must remain connected to the charger for more than 12 hours (example: week-ends) PRELIMINARY CONTROLS Inspect the charger completey for loose screws, electrical connections or other damages;... -
Page 15: Start Of Charge
The EQUALIZATION function, performed by ENERGIC Plus RE chargers, has been developed to keep all the cells of the battery at the same level, even after years of continuous work. -
Page 16: How To Use The Charger [Cabinet C]
How to use the charger [Cabinet C] WARNING ! ENERGIC Plus RE chargers are programmed to do a complete cycle of charge, however it’s recommended to survey the operations when the battery must remain connected to the charger for more than 12 hours (example: week-ends) PRELIMINARY CONTROLS Inspect the charger completey for loose screws, electrical connections or other damages;... -
Page 17: Start Of Charge
The EQUALIZATION function, performed by ENERGIC Plus RE chargers, has been developed to keep all the cells of the battery at the same level, even after years of continuous work. -
Page 18: Trouble Shooting Guide
Battery Charger RE User's Manual Page 18 of 24 OWM-040906-RE Version: 02-AB... - Page 19 Battery Charger RE User's Manual Page 19 of 24 OWM-040906-RE Version: 02-AB...
- Page 20 Battery Charger RE User's Manual Page 20 of 24 OWM-040906-RE Version: 02-AB...
- Page 21 Battery Charger RE User's Manual Page 21 of 24 OWM-040906-RE Version: 02-AB...
- Page 22 Battery Charger RE User's Manual 8. Trouble Shooting Guide SYMPTOM POSSIBLE CAUSES ACTION Battery not connected properly. Check battery connectors/harness. Charger has been connected to Disconnect forkift motor and Charger does not forklift motor connector. connect battery. react to battery being connected, Check charger, connectors and battery polarities.
-
Page 23: Spare Parts List
Battery Charger RE User's Manual 8. Spare Parts List COMMON PARTS – CABINET S POSITION CODE DESCRIPTION 0203340 Base RE box S 0203341 Cover RE box S 0203123 Printcard external plate RE RLCBSRE-06-01 Printcard support (x4) 0201341 Red pushbutton 600380GE/000 Cable strain relief (serial <... -
Page 24: Cabinet Table
Battery Charger RE User's Manual VARIABLE PARTS – CABINET B DESCR. 12-100 24-80 24-100 36-50 36-60 36-80 48-40 48-50 48-60 Rectifier 0201922 0201888 0201889 0201914 0201915 0201888 0201912 0201914 0201915 Printcard 0202751 0202752 0202752 0202753 0202753 0202753 0202754 0202754 0202754 539SCE 10-B 0201067...
