- Page 1 USER MANUAL BATTERY CHARGER RX IN CHARGE OF YOUR BATTERIES www.energicplus.com...
-
Page 2: Table Of Contents
USER MANUAL Table of contents Introduction ........... 3 Responsibility disclaimer . -
Page 3: Introduction
USER MANUAL 1. Introduction This manual contains instructions and suggestions for the users of Energic plus RX battery chargers. Before to install, use or repair the charger, it’s necessary to read and understand this manual completely. It’s recommended to keep the manual in good condition for all the lifetime of the charger. It should be kept in a dry and clean place, always available to the users. -
Page 4: Safety Instructions And Warnings
USER MANUAL 2. Safety instructions and warnings GENERAL Battery chargers can cause injury or death, or damage to other equipment or property, if the user does not strictly observe all safety rules and take precautionary actions. Safe practices must be learned through study and training before using this equipment. -
Page 5: Medical And First Aid Treatment
Inspect all precautionary labels on the equipment. Order and replace all labels that cannot be easily read. 3. Description Energic Plus RX battery chargers have been designed to charge Pb batteries. These units can convert the AC input voltage to a DC voltage at the correct level, in order to charge the battery cells. -
Page 6: Installation Of The Charger
USER MANUAL 4. Installation of the charger Conditions of use: • Operating temperature: 5°C to 45°C • Storage temperature: -20°C to 60°C • Relative humidity: less than 75% CAUTION ! The charger can be installed by qualified personnel only. NOTE Check that the unit’s operating voltage is identical to your local power supply. -
Page 7: Internal View Of The Charger
USER MANUAL INTERNAL VIEW OF THE CHARGER Box S/A/B internal view Box C(RL)/D(RTC)/E(MAXI) internal view... -
Page 8: Electrical Installation Of The Charger
USER MANUAL ELECTRICAL INSTALLATION OF THE CHARGER • Check the efficiency of earth circuitry (yellow/green wire); • Connect the charger to the mains using an adeguate plugs, with pushbutton and fuses; • Use an adeguate plug to connect the charger to the battery; CAUTION ! These settings can be done by qualified personnel only. -
Page 9: Ac Voltage Adjustment - Single Phase - Box B-C
USER MANUAL AC VOLTAGE ADJUSTMENT – SINGLE PHASE – Box B-C • Disconnect the charger from main supply and from the battery; • Open the cabinet; • Find the terminal blocks for AC input voltage setting; • Connect the wires A and B to the desired position. [Check the table to find the correct position]; •... - Page 10 USER MANUAL AC Voltage Setting – Three Phase Box B AC Voltage Setting – Three Phase Box C-D-E...
-
Page 11: Operation
This control is useful to be sure that the electronic control is working correctly. WARNING ! ENERGIC Plus RX chargers are programmed to do a complete cycle of charge, however it’s recommended to survey the operations when the battery must remain connected to the charger for... -
Page 12: Rx Singlephase - Box S-A-B
USER MANUAL NOTE The operations described in these chapters are done by ENERGIC Plus RX chargers automatically. WARNING ! Before disconnecting the battery, check it is not being charged. If it is charging turn off the charger using the main switch or the stop pushbutton, to avoid sparks between connectors. -
Page 13: 567Sce Control Board - Charge Operation
USER MANUAL 567SCE Control Board – CHARGE OPERATION The charge current follows the Wa charge curve as described in the DIN 41774 norm. During the first phase of charge, since the beginning of the charge cycle until the reaching of the gasing point, the led ‘CHARGE ON’... - Page 14 USER MANUAL Final Phase of Charge When the three hours of Final Charge are completed the Control Board 567SCE stops the charge process. The led STOP blinks; the charge process is succesfully completed. End of the charge process If, during the charge process, the AC Input fails the 567SCE Control Board stores in memory the status of the charge process. When the AC Input comes back the charge process starts from the point of interruption.
- Page 15 15 hours. During extra charge cycles the LEDs “ FINAL CHARGE” and “STOP” flash alternately. Equalization Cycle The EQUALIZATION function, performed by ENERGIC Plus RX chargers, has been developed to keep all the cells of the battery at the same level, even after years of continuous work.
-
Page 16: Rx Theephases - Box B
USER MANUAL RX THEEPHASES – BOX B The RX THREEPHASES Chargers made on the Box B mounts the MRG4-3 Control Board. The Front Panel of the MRG4-3 Control Board is composed by 4 Status Led that indicate the state of charge and 3 Leds that indicate the charge current level. - Page 17 USER MANUAL When the gasing point is reached the Final Phase of Charger begins. The Final Phase of charge lasts for 4 hours. During the Final Phase of charge the leds ‘CHARGE ON’ and ‘FINAL CHARGER’ blink alternately. Final Phase of Charge When the four hours of Final Charge are completed the Control Board MRG4-3 stops the charge process.
- Page 18 Equalization Cycle The EQUALIZATION function, performed by ENERGIC Plus RX chargers, has been developed to keep all the cells of the battery at the same level, even after years of continuous work. After the End of 4 Equalization Cycles the Led’ STOP ‘ is fixed ON to indicate that also the equalization cycles have been succesfully completed.
-
Page 19: Mrg4-3 Control Board - Alarms
USER MANUAL MRG4-3 Control Board – ALARMS If the Led ‘Emergency Stop’ blinks means that the charge cycle or an Equalization cycle has been interrupted because an alarm has occurred. The MRG4-3, lighting the current leds on the left, can indicate the cause of the allarm. Stop Pushbutton pressed during the charge cycle or during an equalization cycle. - Page 20 USER MANUAL The battery voltage reached during the charging cycle or during an equalization cycle is too high (over 2,80V/cell). The charge cycle stops. The charge current reached during the charge cycle is too high (over the 140% of the nominal value). The battery voltage hasn’t reached the gassing point within 12 hours of charge.
-
Page 21: Rx Singlephase And Threephases - Box C(Rl) - Box D(Rtc) - Box E
USER MANUAL RX SINGLEPHASE and THREEPHASES – BOX C(RL) – BOX D(RTC) – BOX E (MAXI) The RX Chargers made on the Box C(RL),D(RTC) and E(MAXI) mounts the MRG5-7 Control Board. The Front Panel of the MRG5-7 Control Board is composed by 5 Status Led that indicate the state of charge and 7 Leds that indicate the charge current level. After the connection of the battery, the Control Board turns on. - Page 22 USER MANUAL When the gasing point is reached the Final Phase of Charger begins. The Final Phase of charge lasts for 4 hours. During the Final Phase of charge the leds ‘CHARGE ON’ and ‘FINAL CHARGER’ blink alternately. Final Phase of Charge When the four hours of Final Charge are completed the Control Board MRG5-7 stops the charge process.
- Page 23 USER MANUAL If, during the charge process, the AC Input fails the MRG5-7 Control Board stores in memory the status of the charge process. When the AC Input comes back the charge process starts from the point of interruption. While the AC Input fails all the 4 Status Leds blink alternately.
-
Page 24: Mrg5-7 Control Board - Alarms
USER MANUAL The EQUALIZATION function, performed by ENERGIC Plus RX chargers, has been developed to keep all the cells of the battery at the same level, even after years of continuous work. After the End of 4 Equalization Cycles the Led’ STOP ‘ is fixed ON to indicate that also the equalization cycles have been succesfully completed. - Page 25 USER MANUAL The battery voltage read after the connection of the battery is too low (under 1,60V/cell) The charge cycle doesn’t begin. The battery voltage read after the connection of the battery is too high (over 2,50V/cell) The charge cycle doesn’t begin.
- Page 26 USER MANUAL The battery voltage reached during the charging cycle or during an equalization cycle is too high (over 2,80V/cell). The charge cycle stops. The charge current reached during the charge cycle is too high (over the 140% of the nominal value). The battery voltage hasn’t reached the gassing point within 12 hours of charge.
-
Page 27: Trouble Shooting Guide
USER MANUAL 6. TROUBLE SHOOTING GUIDE Symptom Possible causes Action 1 Battery not connected properly. Check battery connectors/harness. Charger has been connected to forklift Disconnect forkift motor and connect Charger does not motor connector. battery. react to battery Check charger, connectors and battery being connected, 3 Output cables reversed. - Page 28 USER MANUAL Trouble Shooting Connect the battery. Check the battery connection. Does the led “CHARGE ON” light on? Are output cables polarity reversed? Does the charge turn on See Note A3. after 5 seconds? ATTENTION: An output cables inversion can demage the rectifier. Is the charger current to low? See Note A.
- Page 29 USER MANUAL ............................
- Page 30 USER MANUAL ............................
- Page 31 USER MANUAL ............................
- Page 32 info@energicplus.com • www.energicplus.com TVH Parts NV • Brabantstraat 15 • 8790 Waregem • Belgium...
