CCD Specifications
(continued)

KAF 1400

Detection Mode
High Signal to
Noise
High Dynamic
Range
High Sensitivity
* Binning must be a minimum of 2 pixels in the parallel and serial direction to reach the maximum ADC signal.
H x V: 1317 x 1035
Pixel Size: 6.8µm x 6.8µm
Gain
Relative
Setting
Gain
1
1
/
x
2
≈1x
2
≈4x
3
60
50
40
30
20
10
0
400
500
Typical QE Curve (not installed in camera)
QE response in the 200-400 nm range can be enhanced with Photometrics' proprietary Metachrome II coating.
Typical
Noise
System Gain
≈20e
-
-
20e
/ADU
-
≈10e
-
17e
/ADU
-
≈2.5e
-
12e
/ADU
600
700
Wavelength (nm)
Chapter 6. Specifications
Typical Maximum ADC
Signal
-
80Ke
(binned full well*)
-
40Ke
(single pixel full
well)
-
10Ke
(high sensitivity)
800
900
1000
35
