F-Mount Adapter - Photometrics SenSys User Manual

F-Mount Adapter

26
SenSys User Manual
Side View of F-mount (unmounted)
Threads at
32 threads/inch
Side View of F-mount (mounted) for KAF 0400 and KAF 1600
Threads at
32 threads/inch
Side View of F-mount (mounted) for KAF 1400
1.93 in dia.
(49.0 mm)
Top View of F-mount
2.35 in dia.
(59.7 mm)
2.50 in dia.
(63.5 mm)
CCD Focal Plane
CCD Focal Plane
2.50 in dia.
(63.5 mm)
.67 in
(17.0 mm) 1.02 in
(25.9 mm)
1.72 in
(43.7 mm)
minimum distance
1.05 in
(26.7 mm)
1.74 in
(44.2 mm)
minimum distance
1.07 in
(27.2 mm)
