Tripod Camera
Stand
10
SenSys User Manual
The SenSys camera has four mounting holes that are tapped for a standard
tripod mounting bolt.
Tripod Mounts
(0.25"-20 UNC-2B)
To mount the SenSys camera on a tripod camera stand:
1. Loosen the tripod mount locknut so that the maximum length of the
tripod mounting bolt is exposed.
2. Align the camera on the tripod mounting bolt, using one of the four
mounting holes on the camera body.
3. Thread the tripod mounting bolt into the camera body.
4. Tighten the locknut on the mount to secure the camera.
To remove the SenSys camera from a tripod mount:
1. Loosen the tripod mount locknut.
2. Unthread the tripod mounting bolt from the camera.
on 4 sides
Camera with Tripod Camera Stand
