Power Brick
28
SenSys User Manual
The power supply is a +5V DC and ±15V DC brick with 100-240V AC input at
50-60 Hz. The maximum power output is 55 W.
6.97 in
(177.0 mm)
2.25 in
(57.1 mm)
3.74 in
(95.0 mm)
