Chapter 3. Configuration Options
The SenSys hardware configuration options allow you to adapt your camera to
standard scientific instruments and lenses. Removable F-mount and C-mount
adapters, F-mount and C-mount lenses, and a tripod camera stand are available
through Photometrics.
Lens Mount
SenSys cameras are shipped with a removable F-mount adapter or C-mount
Adapters
adapter installed. The F-mount adapter allows the camera to be attached to
lenses and scientific instruments that are compatible with a Nikon
mount. The C-mount adapter allows the camera to be attached to many video
camera lenses and C-mount-compatible scientific instruments. The F-mount
adapter is secured with two #6-32 socket set screws; the C-mount adapter is
secured with two #4-40 socket set screws.
C-Mount
Adapter
F-Mount
Adapter
SenSys Mount Options
®
bayonet
C-Mount Lens
(optional)
F-Mount Lens
(optional)
7
