Chapter 6. Specifications

Camera

Weight: 3 lbs without lens or lens mount
Width: 4.48 in (113.7 mm)
Length: 7.15 in (181.6 mm)
Thickness: 3.00 in (76.2 mm) for F-mount; 2.66 in (67.6 mm) for C-mount
Window thickness: 1 mm
Distance from top of shutter cover to CCD image plane:
Distance from top of window to CCD image plane:
Maximum ambient operating temperature: 40°C (104°F)
Minimum ambient operating temperature: 0°C (32°F)
Power dissipation: 15 watts
CCD
0400 and 1600
1400
CCD
0400 and 1600
1400
4.48 in
(113.8 mm)
Camera Front View
F-mount Distance C-mount Distance
1.05 in (26.7 mm) .63 in (16.0 mm)
1.07 in (27.2 mm) .65 in (16.6 mm)
F-mount Distance C-mount Distance
.24 in (6.1 mm) .24 in (6.1 mm)
.26 in (6.6 mm) .26 in (6.6 mm)
7.15 in
(181.6 mm)
23
