Summary of Contents for Endura TWC2M
-
Page 1: User Manual
™ Dual Unit Rapid Charger FOR RECHARGEABLE LMR BATTERIES User Manual Model TWC2M... -
Page 2: Table Of Contents
ENDURA™ TWC2M Table of Contents Topic Page Introduction Important Caution Features Replacing A Charging Pod Charging A Battery – 7 Battery Fault Conditions Warranty And Service – 10 Specifications... -
Page 3: Introduction
The TWC2M can charge two batteries at the same time and the batteries may be the same or different chemistries. Separate LEDs confirm the charge status of each battery. -
Page 4: Important
Important Read all Caution statements below and this User Manual before attempting to charge a battery. Check to make sure a charging pod compatible with your battery is properly installed on charger before placing battery in pod. Position charger away from TVs, radios, or other receivers to prevent the charger from interfering with these types of products. -
Page 5: Caution
Do not remove the charger’s housing or make any modification to the charger. Use only the power supply provided with the ENDURA TWC2M charger. If a replace- ment power supply is required, order part number TWC2M-PS. Use of other power... -
Page 6: Features
ENDURA TWC2M Features Power supply. Removable charging pod. Power connection – back of charger. TWC2M – dual unit rapid charger base. Charge status LEDs – for front and rear positions. Note: Quick reference information for charge status LEDs is located... -
Page 7: Replacing A Charging Pod
Do not over tighten the screw. Inspect the charging contacts to ensure they are clean and unobstructed. Connect the power supply to the TWC2M. You are now ready to charge a battery com- patible with the charging pod. -
Page 8: Charging A Battery
The battery may be charged while attached to the radio and two batteries may be charged simultaneously. R - Status LED for rear position. F - Status LED for front position. P - Illuminates GREEN when TWC2M is connected to power. - Page 9 Allow the charge status LED to go off before placing another bat- tery in the charging pod. Use the TWC2M at room temperatures between 15°C and 30°C (59° F – 86° F). Charging batteries at temperatures outside this range may result in under charging of batteries.
-
Page 10: Battery Fault Conditions
Fault Conditions When the F or R charge status LED flashes RED, a fault condition exists. There are three different flash patterns, each indicating a specific type of fault. The flash patterns and fault conditions are as follows: Flash Pattern Fault Type Flashes 1 Time Indicates charging complete, but battery is under charged. -
Page 11: Warranty And Service
Warranty And Service During Warranty The ENDURA TWC2M is made from high quality materials and designed to provide years of reliable service. The following warranty applies: Power Products Unlimited, Inc. (PPU) warrants this product to be free from defects in workmanship and materials for one-year from date of purchase by the end user. - Page 12 Send item to Power Products – Warranty Service Department, 2170 Brandon Trail, Alpharetta, GA 30004. For your protection, we recommend you obtain proof of delivery for your shipment. Include with your product, dated proof of purchase, your name and daytime telephone number, and return address (street address only;...
-
Page 13: Specifications
ENDURA TWC2M Specifications Dimensions 101 x 137 x 81 mm / 3.9 x 5.4 x 3.2 inches (W x L x H) Weight 290 g / .64 lbs (Charger Only) Compatible Chemistries NiCd / NiMH / Li-Ion / LiPo Recommended Operating Temperature 15º... - Page 14 Smart • Adaptable • Reliable © 2014 Power Products Unlimited, Inc. Power Products is a registered trademark of Power Products Unlimited, Inc. ENDURA and Smart • Adaptable • Reliable are trademarks of HT Mobile Products, Inc. All rights reserved.
