- Page 1 ™ Dual Unit Rapid Charger FOR RECHARGEABLE LMR RADIO BATTERIES User Manual Model: EC2M...
-
Page 3: Table Of Contents
Table of Contents Topic Page Introduction Important (read before use) Caution (read before use) EC2M Features Accessories For In-Vehicle Installation 5 – 6 Replacing A Charging Pod Charging A Battery 8 – 9 Fault Conditions & Advisements 10 – 11 Warranty And Service 12 –... -
Page 4: Introduction
Introduction Thank you for purchasing an ENDURA™ EC2M, Dual Unit Rapid Charger. This high quality product is designed for desktop use or in-vehicle use with optional accessories. The EC2M can charge two batteries at the same time and the batteries may be the same or different chemistries. -
Page 5: Important (Read Before Use)
Important Read all Caution statements below and this User Manual before attempting to charge a battery. Check to make sure a charging pod compatible with your battery is properly installed before charging a battery or installing the charger in a vehicle. Always charge new batteries completely before initial use. -
Page 6: Caution (Read Before Use)
Caution Based on the pod selected, EC2M can charge Li-Ion / LiPo or NiMH / NiCd batteries. If the pod is designed for Li-Ion / LiPo only, do not attempt to charge NiMH / NiCd batteries. If the pod is designed for NiMH / NiCd only, do not attempt to charge Li- Ion / LiPo batteries. -
Page 7: Ec2M Features
EC2M Features Removable charging pod. Power supply. EC2M – dual unit rapid charger base. DC power connection – back of charger. Charge status LEDs – for front and rear positions. Note: Quick reference information for charge status LEDs is located... -
Page 8: Accessories For In-Vehicle Installation
Accessories For In-Vehicle Installation The items below are available for EC2M and allow the charger to be used in a vehicle. Mounting bracket for dash or floor mounting (TWC2M-MB). 1A. Adjustable tie-down straps for front and rear positions. 1B. Holes for attaching to optional floor mounting bracket (LEVCA-MHD) or other bracket with 4-hole AMPS pattern. -
Page 10: Replacing A Charging Pod
Do not over tighten the screw. Inspect the charging contacts to ensure they are clean and unobstructed. Connect the power supply or vehicle power adapter to the EC2M. You are now ready to charge a battery compatible with the charging pod. -
Page 11: Charging A Battery
LED (F or R) will illuminate RED with no flashing to indicate normal charging. R - Status LED for rear position. F - Status LED for front position. P - Illuminates GREEN when EC2M is connected to power. - Page 12 Allow the charge status LED to go off before placing another battery in the charging pod. EC2M is designed to charge batteries with a temperature monitoring circuit when the battery temperature is between 0°C and 45°C (32° F – 113° F); batteries outside this temperature will not be charged.
-
Page 13: Fault Conditions & Advisements
Fault Conditions & Advisements When the charge status LED flashes RED, a fault condition exists. A fault condition requires immediate attention. When the status LED is solid or flashes ORANGE, you are receiving an advisement about the battery. The flash patterns for fault conditions are as follows: LED Pattern Fault Description Flashes RED... -
Page 14: Fault Conditions & Advisements
Fault Conditions & Advisements (continued) The flash patterns for advisements are as follows: LED Pattern Advisement Solid ORANGE Brief reset period for charger after battery is removed. Allow the LED to go off before inserting another battery. (Battery removed.) Solid ORANGE Indicates battery is too cold when initially inserted. - Page 15 Warranty And Service During Warranty The EC2M is made from high quality materials and designed to provide years of reliable service. The following warranty applies: Power Products Unlimited, LLC (PPU) warrants this product to be free from defects in workmanship and materials for one-year from date of purchase by the end user. This warranty applies to the original purchaser and is void if the product has been altered, misused, damaged, neglected, or if repair is required because of normal wear and tear.
-
Page 16: Warranty And Service
Warranty And Service During Warranty (continued) Send item to Power Products – Warranty Service Department, 2170 Brandon Trail, ρ Alpharetta, GA 30004. For your protection, we recommend you obtain proof of delivery for your shipment. Include with your product, dated proof of purchase, your name and daytime tele- ρ... -
Page 17: Specifications
EC2M Specifications Dimensions 101 x 137 x 81 mm / 3.9 x 5.4 x 3.2 inches (W x L x H) Weight 290 g / .64 lbs (Charger Only) Compatible Chemistries Li-Ion / LiPo / NiMH / NiCd (based on pod selected) Ambient Operating Temperature 5º... -
Page 18: Accessories
Accessories (EC2M) Information Part Number Description TWC2M-PS Power supply. UL listed. Input: 100-240V, 50-60Hz, 0.58A. (Included with EC2M.) Output: 15.0V, 1.6A. TWC6M-VPA Heavy duty vehicle power adapter. Length: 24.0” / 6A. (cord relaxed). Replaceable fuse, 6A. TWC6M-HW Hardwire kit for in-vehicle Length: 13.0’. - Page 20 2170 Brandon Trail • Alpharetta, GA 30004 www.powerproducts.com ©2018 Power Products Unlimited, LLC. Endura Chargers By Power Products Power Products, Endura, and Smart-Adaptable-Reliable are trademarks of Smart – Adaptable – Reliable Power Products Unlimited, LLC. All rights reserved. ™...
