Page 1: Users Manual
ES-3112 G/R/C/S/V-XA 12.1" Open-Frame LCD Monitor with Anti-glare Glass/ Resistive / Capacitive / 3mm SAW / 6 mm Vandal Proof SAW Touchscreens Users Manual... - Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
- Page 3 Step 1. Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Step 2. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance. Please have the following information ready before...
- Page 4 Safety Instructions Read these safety instructions carefully. Keep this User's Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for clean- ing. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
-
Page 5: Table Of Contents
Cut-out Dim. for ES-3112 G/R/C/S/V-XA Rear Mnt..21 Figure 3.2:ES-3112 XA Dimensions of Cut-off..21 Mounting Guide .............. 21 Figure 3.3:Rear Mnt of the ES-3112 G/R/C/S/V-XA .. 22 Exploded Diagrams ............23 3.5.1 Exploded Diagram of ES-3112 G/R/C-XA ....23 Figure 3.4:Exploded Diagram of ES-3112 G/R/C-XA 23... - Page 6 ADC Board..............26 Figure 3.7:Locating Connectors on the ADC Board .. 26 DC to AC Inverter ............26 Figure 3.8:Locating Connectors on DC/AC Inverter ... 26 Touch Screen Control Board........... 27 Figure 3.9:Locating Conn. of ES-3112C Cont. Board 27 Figure 3.10:Locating Conn. of ES-3112R Cont.Board 27 Figure 3.11:Locating Conn.
- Page 7 General Information This chapter introduces ES-3112, its features and specifications. Sections include: • Introduction • Product Features • VGA Signal • LCD Specifications • LCD Pin Definitions • Touchscreen Definitions • External AC Power Adapter • Environmental Specifications...
-
Page 8: Chapter 1 General Information
Chapter 1 General Information 1.1 Introduction This product, an LCD touch monitor, is mainly focused on the Kiosk mar- ket or Human Machine Interfaces (HMI). It is a core module for Kiosk application. The LCD touch monitor supports direct VGA analog signal inputs, which make it more compatible and adaptable to connect to com- puters widely used in the current market. -
Page 9: Vga Signal
• OSD Controls: allow on-screen adjustments of Brightness, Contrast, RGB Auto Color Balance, H-Position, V-Position, Clock, Phase. • Power Supply: DC input 12 V / 4.0 A Internal functions • ADC Core logic chipset: M-Star MST9010; built-in high speed clock recovery circuit and PLL circuit;... -
Page 10: Lcd Specifications
1.4 LCD Specifications 1.4.1 LCD Specifications Display Type 12.1” SVGA TFT LCD Active Area (mm) 246.0 X 184.5 Resolution 800 x 600 Dot Pitch (mm) 0.3075 x 0.3075 Supply Voltage (Panel) 12 Vdc Viewing angle (v,h) 90°, 120° Contrast 500:1 Luminance (cd/m2) Color 262144... -
Page 11: Lcd Pin Definitions
1.4.2 LCD Pin Definitions Chapter 1... -
Page 12: Touchscreen Specifications
1.5 Touchscreen Specifications 1.5.1 ES-3112C-XA (Capacity) • Type: 3M Touch Systems-Microtouch capacity touch screen • Resolution: 1024 x 1024 • Light Transmission: 85% • Touch Life Cycle: 225 million • Controller: RS-232 interface • Communication speed: up to 19.2K baud. •... -
Page 13: Es-3112V-Xa (6Mm Saw)
1.5.4 ES-3112V-XA (6mm SAW) • Type: EloTouch Surface Acoustic Wave (6 mm SAW) • Resolution: 4096 x 4096 • Light Transmission: 91% • Touch Life Cycle: 50 millions • Controller: RS-232 interface • Communication speed: up to 19.2K baud. • Power consumption: +5 V @ 60 mA 1.6 External AC Power Adapter •... - Page 14 ES-3112 Users Manual...
- Page 15 System Setup This chapter shows how to get started with ES-3112. Sections include: • Introduction • Preparing for first-time use • I/O Arrangement • Installation Procedure • OSD Control • Enable Capacitive Touchscreen Driver (ES-3112C-XA) • Enable Resistive Touchscreen driver (ES-3112R-XA) •...
-
Page 16: Chapter 2 System Setup
Chapter 2 System Setup 2.1 Introduction This chapter describes basic features and procedures for using the Open- frame LCD monitor. Topics covered include the system installation, OSD control, Touchscreen and so on. 2.2 Preparing for First-time Use Before you start to set up the ES-3112 LCD Monitor, you should have at least the following items ready in your accessory box: •... -
Page 17: Installation Procedure
2.4 Installation Procedure ES-3112 can only be powered by an AC electrical outlet adapter (90 ~ 240 volts). Be sure to always handle the power cord and power adapter by holding the plug ends only. 1. Make sure that the system power is turned off. 2. -
Page 18: Osd Screen
Adjusting with OSD Control Five different keys are defined for operation. They are labeled on the key- pad. (Power KEY) is designated for Power On/Off [Menu] (Menu KEY) is designated for Menu/Enter function depending on the selected item. Pressing [Menu] will open the OSD menu. -
Page 19: Horizontal Position
OSD Function List Auto Adjust Automatically adjusts H-position, V-position, Pixel Clock and Phase for an optimal image. Press “Menu” to execute Brightness Adjust the Brightness Press “INC” or “DEC” to adjust the parameter Contrast Adjust the difference between the light and dark areas Press”... -
Page 20: Install Capacitive Touchsc. Driver (Es-3112C-Xa)
Switch Color Adjust color temperature Press” INC” or “DEC” to select a color mode Set Color USER Adjust color temperature for User mode OSD Language Change OSD language Press” INC” or “DEC” to select, and press “Menu” to execute Exit Exit the OSD menu and save the values Press “Menu”... -
Page 21: Install Resistive Touchsc. Driver (Es-3112R-Xa)
2.7 Install Resistive Touchsc. Driver (ES-3112R-XA) The resistive touchscreen of ES-3112R-XA is patented technology avail- able from Elotouch System. It is an ideal choice for unattended kiosks and POI applications in public places like train stations, airports, malls, and supermarkets. ES-3112R-XA provides 1 CD kit which contain resistive driver. -
Page 22: Install Saw Touchscreen Driver (Es-3112S-Xa)
2.8 Install SAW Touchscreen Driver (ES-3112S-XA) The SAW touchscreen of ES-3112S-XA is patented technology available from Elotouch System. Its tough, scratch-resistant and wear-resistant fea- ture is an ideal choice for unattended kiosks and POI applications in pub- lic places like train stations, airports, malls and supermarkets. ES-3112S-XA provides 1 CD kit which contains a SAW driver. -
Page 23: Install 6 Mm Touchscreen Driver (Es-3112V-Xa)
2.9 Install 6 mm Touchscreen Driver (ES-3112V-XA) The 6 mm touchscreen of ES-3112V-XA is patented technology available from Elotouch System. Its tough, scratch-resistant and Impact-resistant feature is a ideal choice for unattended kiosks and POI applications in public places like train stations, airports, malls, supermarket, and etc. ES-3112V-XA provides 1 CD kit which contain SAW driver. - Page 24 ES-3112 Users Manual...
- Page 25 This chapter includes specifications related to dimensions, mounting and PCBs. Sections include: • Introduction • Mechanical Dimensions • Cut-out Dimensions for ES-3112 G/ R/C/S/V-XA Rear Mounting • Mounting Guide • Exploded Diagrams • Electrical Block Diagram • ADC Board • DC to AC Inverter...
-
Page 26: Chapter 3 Specifications
Chapter 3 Specifications 3.1 Introduction The mechanical design concept of ES-3112 G/ R/C/ S/ V -XA follows easy assembling, easy maintenance principles. Two main metal parts are used to support the PCB, LCD panel, and touch screen. Basically, front frame and back frame form a space to contain all parts of the LCD touch monitor. -
Page 27: Cut-Out Dim. For Es-3112 G/R/C/S/V-Xa Rear Mnt
3.3 Cut-out Dimensions for ES-3112 G/R/C/S/V-XA Rear Mounting To construct a suitable panel, refer to the following cutout & elongated holes dimension diagram. Figure 3.2: ES-3112 XA Dimensions of Cut-off. 3.4 Mounting Guide To mount the ES-3112G/R/C/S/V-XA into a panel or kiosk: 1. - Page 28 Figure 3.3: Rear Mounting of the ES-3112 G/R/C/S/V-XA ES-3112 Users Manual...
-
Page 29: Exploded Diagrams
3.5 Exploded Diagrams 3.5.1 Exploded Diagram of ES-3112 G/R/C-XA Figure 3.4: Exploded Diagram of ES-3112 G/R/C-XA Chapter 3... -
Page 30: Exploded Diagram Of Es-3112 S/V -Xa
3.5.2 Exploded Diagram of ES-3112 S/V -XA Figure 3.5: Exploded Diagram of ES-3112S/V-XA ES-3112 Users Manual... -
Page 31: Electrical Block Diagram
3.6 Electrical Block Diagram The product concept is a combination of a 12.1” LCD panel and a touch- screen. In order to reduce the depth of the LCD touch monitor and solve cooling problems at the same time, a DC input is designed to remove the AC switching power supply. -
Page 32: Adc Board
3.7 ADC Board The ADC board is used to convert RGB signal to LCD digital signal and send to LCD panel to display. The ADC board is as below: Figure 3.7: Locating Connectors on the ADC Board 3.8 DC to AC Inverter The DC to AC inverter is used to provide power to the LCD backlight. -
Page 33: Touch Screen Control Board
3.9 Touch Screen Control Board Except ES-3112G-XA, all other ES-3112 series provide various touch screens with different technical. For ES-3112C-XA, it use 3M ’s Capacity Touch Screen sensor and has the control board as below: Figure 3.9: Locating Connector of ES-3112C Control Board ES-3112R-XA uses the ELO’s resistive touch screen as shown below: Figure 3.10: Locating Connector of ES-3112R Control Board Chapter 3... -
Page 34: Control Board
