INTRODUCTION
This service manual describes the latest service information
for the IC-F3061T/S, IC-F3062T/S and IC-F3063T/S VHF
TRANSCEIVER at the time of publication.
MODEL VERSION SYMBOL CHANNEL SPACING KEY PAD
IC-F3061T
U.S.A [USA-01]
IC-F3061S
IC-F3062T
[EUR-01]
IC-F3062S
Europe
IC-F3062S
(BOS [FRG-01]
compatible)
IC-F3063T
General [GEN-01]
IC-F3063S
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
CAUTION
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 7.2 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW) to
the antenna connector. This could damage the transceiver's
front-end.

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom parts numbers
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
5030002830 LCD M4-0078TAY-2
8810009220 Screw PH B0 M2×8 ZK (BT) IC-F3061T
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and
Kingdom, Germany, France, Spain, Russia and/or other countries.
10-key
15.0 kHz/30.0 kHz
4-key
10-key
12.5 kHz/25.0 kHz
4-key
20.0 kHz
10-key
12.5 kHz/20.0 kHz
/25.0 kHz
4-key
IC-F3061T Front unit 5 pieces
Chassis 10 pieces
logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United

REPAIR NOTES

1. Make sure the problem is internal before disassembling
the transceiver.
2. DO NOT open the transceiver until the transceiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
transceiver is defective.
6. DO NOT transmit power into a Standard Signal
Generator or a Sweep Generator.
7. ALWAYS connect a 50 dB to 60 dB attenuator between
the transceiver and a Deviation Meter or Spectrum
Analyzer when using such test equipment.
8. READ the instructions of test equipment throughly
before connecting a test equipment to the transceiver.
An
