INTRODUCTION
This service manual describes the latest service information
for the IC-208H VHF/UHF FM TRANSCEIVER at the time at
the time of publication.
MODEL VERSION
Taiwan
U.S.A.
Korea
IC-208H
Australia
Export
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit order numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1140005990 S.IC MB15A02PFV-1 IC-208H
8810009610 Screw FH M2.6×6 ZK IC-208H
Addresses are provided on the inside back cover for your
convenience.
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 16 V. This will ruin the
transceiver.
DO NOT expose the transceiver to rain, snow or any liquids.
SYMBOL
TPE
DO NOT reverse the polarities of the power supply when con-
necting the transceiver.
USA
KOR
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the transceiv-
AUS
er's front end.
EXP
1. Make sure a problem is internal before disassembling the
2. DO NOT open the transceiver until the transceiver is
3. DO NOT force any of the variable components. Turn
4. DO NOT short any circuits or electronic parts. An insu-
5. DO NOT keep power ON for a long time when the trans-
MAIN UNIT 5 pieces
6. DO NOT transmit power into a signal generator or a
Bottom cover 10 pieces
7. ALWAYS connect a 50 dB to 60 dB attenuator between
8. READ the instructions of test equipment thoroughly
DANGER

REPAIR NOTES

transceiver.
disconnected from its power source.
them slowly and smoothly.
lated tuning tool MUST be used for all adjustments.
ceiver is defective.
sweep generator.
the transceiver and a deviation meter or spectrum ana-
lyzer when using such test equipment.
before connecting equipment to the transceiver.
