Supero SuperWorkstation PIO-737A-i-MA015 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
W
uper
orkstation
PIO-737A-i-MA015
USER'S MANUAL
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperWorkstation PIO-737A-i-MA015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero SuperWorkstation PIO-737A-i-MA015

Summary of Contents for Supero SuperWorkstation PIO-737A-i-MA015

  • Page 1 UPER ® uper orkstation PIO-737A-i-MA015 USER’S MANUAL...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperWorkstation PIO- 737A-i-MA015. Installation and maintenance should be performed by experienced technicians only. Manual Organization Chapter 1: Workstation Overview The fi...

  • Page 4: Table Of Contents

    System Power ....................1-3 SATA Support ....................1-3 Front Control Panel ..................1-3 Cooling System ....................1-3 Control Panel ....................1-3 Contacting Supermicro ..................1-6 Chapter 2 Workstation Setup Unpacking the System ..................2-1 Preparing for Setup ..................2-1 Motherboard Layout ..................2-2 Jumper Settings ....................
  • Page 5 Table of Contents Power Supply ....................3-16 Motherboard Battery ..................3-17 Appendix A Software Operating System ................... A-1 System Recovery Instructions................. A-1 Support ......................A-1 Installing Drivers ....................A-2 SuperDoctor III ....................A-3 BIOS ........................ A-4 Starting BIOS Setup Utility ................A-4 How To Change the Confi...
  • Page 6 uper orkstation PIO-737A-i-MA015 User's Manual Notes viii...

  • Page 7: Chapter 1 Workstation Overview

    Chapter 1 Workstation Overview Introduction The PIO-737A-i-MA015 is a high-end turnkey workstation. A replacement parts list is shown below. A complete list of safety warnings is provided on the Supermicro web site at http://www.supermicro.com/about/policies/safety_information.cfm Replacement Parts List Qty. Defi nition...

  • Page 8: Motherboard Features

    PIO-737A-i-MA015 User's Manual Motherboard Features The SuperWorkstation PIO-737A-i-MA015 uses the X9DAi, a dual processor moth- erboard built around the Intel® C600 series chipset. Below are the main features of the X9DAi. Processors The PIO-737A-i-MA015 supports single or dual Intel E5-2600 processors in LGA 2011 sockets.

  • Page 9: Chassis Features

    Chapter 1: Workstation Overview Chassis Features The PIO-737A-i-MA015 is a workstation. The following is a general outline of the main features of the enclosure. See Figure 1-3 for a front view. System Power The PIO-737A-i-MA015 features a low-noise, high-effi ciency 665W power supply. Power must be removed from the system before servicing or replacing the power supply.
  • Page 10 uper orkstation PIO-737A-i-MA015 User's Manual Figure 1-1. Control Panel Header Pins Ground x (Key) x (Key) Power On LED HDD LED NIC1 LED NIC2 LED OH/Fan Fail LED Power Fail LED Ground Reset (Button) Ground Power (Button) Figure 1-2. I/O Ports I/O Backpanel 1.
  • Page 11 Chapter 1: Workstation Overview Figure 1-3. Front View of Workstation...

  • Page 12: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 13: Chapter 2 Workstation Setup

    If the system itself shows damage you should fi le a damage claim with the carrier who delivered it. Review the warnings and cautions, which may also be found on the Supermicro Web site at http://www.supermicro.com/about/policies/safety_information.cfm. Preparing for Setup Decide on a suitable location for the workstation.

  • Page 14: Motherboard Layout

    uper orkstation PIO-737A-i-MA015 User's Manual Motherboard Layout This section provides details on the motherboard and jumper settings that may be useful when setting up the system. Figure 2-1. Layout P2 DIMMG1 JPI2C1 P2 DIMMG2 JPWR1 JPWR2 FAN1 P2 DIMMH1 P1 DIMMA1 P2 DIMMH2 P1 DIMMA2 P1 DIMMB1...
  • Page 15 Chapter 2: Workstation Setup Motherboard Headers/Connectors Jumper Description Default Setting JBT1 Clear CMOS See Section 5-10 SMBus En/Disable Pins 1-2 (Enabled) JPI1 IEEE1394a En/Disable Pins 1-2 (Enabled) JPL1/2 GLAN1/GLAN2 En/Disable Pins 1-2 (Enabled) JPME1 ME Recovery Pins 2-3 (Normal) JPP0 JTAG Scan Pins 2-3 (CPU 1 only) JPP1...

  • Page 16: Jumper Settings

    uper orkstation PIO-737A-i-MA015 User's Manual Jumper Settings Explanation of Jumpers To modify the operation of the mother- board, jumpers can be used to choose Connector between optional settings. Jumpers Pins create shorts between two pins to change the function of the connector. Pin 1 is identifi...
  • Page 17 Chapter 2: Workstation Setup GLAN Enable/Disable GLAN Change the setting of jumper JPL1 or Jumper Settings JPL2 to enable or disable the LAN1 Jumper Setting Defi nition and LAN2 Ethernet ports, respectively. Enabled (default) See the table on the right for jumper Disabled settings.
  • Page 18 uper orkstation PIO-737A-i-MA015 User's Manual Manufacture Mode Jumper JPME1 allows the user to fl ash the system fi rmware from a host ME Mode Select Jumper Settings server to modify system settings. Jumper Setting Defi nition Close this jumper to bypass SPI fl ash Pins 1-2 Manufacture Mode security, and force ME into recovery...

  • Page 19: Onboard Indicators

    Chapter 2: Workstation Setup Onboard Indicators LAN1/2 LEDs LAN1/2 LED The Ethernet ports (located beside (Connection Speed Indicator) the VGA port) have two LEDs. On LED Color Defi nition each port, one LED indicates activity No Connection or 10 Mb/s while the other LED may be green, Green 100 Mb/s...
  • Page 20 uper orkstation PIO-737A-i-MA015 User's Manual Notes...

  • Page 21: Chapter 3 Component Installation

    Caution: Except for short periods of time, do NOT operate the system without the cover in place. The chassis cover must be in place to allow for proper airfl ow and to prevent overheating. Additional warnings and cautions can be found on the Supermicro Web site at http:// www.supermicro.com/about/policies/safety_information.cfm.

  • Page 22: Adding Pci Add-On Cards

    uper orkstation PIO-737A-i-MA015 User's Manual Figure 3-1. Removing the Chassis Side Covers Adding PCI Add-On Cards The PIO-737A-i-MA015 can accommodate standard size add-on cards populated in all slots. Installing an Add-on Card 1. Begin by removing power from the system as described on page 3-1. 2.

  • Page 23: Installing A Cpu And Heat Sink

    4. When a motherboard has no CPU pre-installed, make sure that the plastic CPU socket cap is in place and none of the socket pins are bent. 5. Refer to the Supermicro Web site for updates on CPU support. Installing an LGA 2011 Processor...
  • Page 24 uper orkstation PIO-737A-i-MA015 User's Manual 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate fi...
  • Page 25 Chapter 3: Component Installation Caution: CPUs only install to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 26: Installing A Cpu Heat Sink

    uper orkstation PIO-737A-i-MA015 User's Manual Installing a CPU Heat Sink 1. Do not apply any thermal grease to the heat sink or the CPU die; the required amount has already been applied. 2. Place the heat sink on top of the CPU so that the four mounting holes are aligned with those on the motherboard and the heat sink bracket underneath.

  • Page 27: Removing The Heat Sink

    Chapter 3: Component Installation Removing the Heat Sink Preparation 1. Begin by removing power from the system as described on page 3-1. 2. Remove the power cord from the system before removing the heatsink. 3. Unscrew the heat sink screws from the motherboard in the sequence as shown in the illustration below.

  • Page 28: Installing Memory Modules

    PIO-737A-i-MA015 User's Manual Installing Memory Modules Check the Supermicro Web site for recommended memory modules. Caution: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Preparation 1. Begin by removing power from the system as described on page 3-1.

  • Page 29: Memory Support

    The Super Workstation supports up to 512 GB of registered/unbuffered load reduc- ing ECC DDR3 1333/1066/833 memory in 16 DIMM slots. For the latest memory updates, please refer to the product page on the Supermicro website. Order of Populating DIMM Slots For memory to work properly, follow the table below for the correct order of populat- ing the DIMM slots.
  • Page 30 uper orkstation PIO-737A-i-MA015 User's Manual UDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated by DIMM & Data Per DIMM (Note 1) Slot Per Channel (SPC) and DIMM Per Width Channel (DPC) (Notes 2, 3, 4) 2 Slots Per Channel 1DPC 2DPC 1.35V...
  • Page 31 Chapter 3: Component Installation LRDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage DIMM & Data Per DIMM (Note 2) Validated by Slot Per Width (Note 1) Channel (SPC) and DIMM Per Channel (DPC) (Notes 3, 4, 5, 6) 2 Slots Per Channel 1DPC/2DPC 1.35V...

  • Page 32: System Fan

    Installing a New Fan 1. Replace the failed fan with an identical one (available from Supermicro) 2. Install it in the same position and orientation as the one you removed. 3. Check that the fan is working, then replace the chassis cover.

  • Page 33: Hard Drive Installation

    Chapter 3: Component Installation Hard Drive Installation A total of four SATA drives may be housed in the PIO-737A-i-MA015. The drive IDs are preconfi gured as 0 through 3 in order from bottom to top. Remove the side panel of the chassis to access these drives as described previously in this chapter. Caution: Regardless of how many SATA drives are installed, all drive carriers must remain in the drive bays to promote proper airfl...
  • Page 34 uper orkstation PIO-737A-i-MA015 User's Manual Figure 3-6. Removing the Drive Carrier Figure 3-7. Removing a Hard Drive from the Drive Carrier 3-14...

  • Page 35: Installing Components In The 5.25" Drive Bays

    Chapter 3: Component Installation Installing Components in the 5.25" Drive Bays The PIO-737A-i-MA015 has two 5.25" drive bays above the SATA drive bays. Components such as a hard drives or CD-ROM drives can be installed in these 5.25" drive bays. Preparation Begin by removing power from the system as described on page 3-1.

  • Page 36: Power Supply

    uper orkstation PIO-737A-i-MA015 User's Manual Figure 3-8. Adding a Component Without a Drive Carrier Power Supply The PIO-737A-i-MA015 includes a single 665 Watt power supply. In the unlikely event that it becomes necessary to replace the power supply, follow the instruc- tions below..

  • Page 37: Motherboard Battery

    Chapter 3: Component Installation Motherboard Battery CAUTION: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarities (see Figure 3-12). This battery must be re- placed only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 38 uper orkstation PIO-737A-i-MA015 User's Manual Notes 3-18...

  • Page 39: Appendix A Software

    Support If you require technical help for any Operating System problems, please contact your 3rd party software vendor or Technical Support at Supermicro. Contact information is provided in Chapter 1.

  • Page 40: A-2 Installing Drivers

    A-2 Installing Drivers With the hardware and operating system installed, you may need to install the drivers if not done already. The drivers are available online at http://www.supermicro.com/support/resources/ Obtaining Drivers 1. Go to the Advanced Search area and select the Category (motherboards), Product Type and Model (motherboard model) from the drop-down menus.

  • Page 41: A-3 Superdoctor Iii

    Appendix A: Software A-3 SuperDoctor III ® The SuperDoctor III program is a Web based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program included on the CD-ROM that came with your motherboard allows you to monitor the en- vironment and operations of your system.

  • Page 42: Superdoctor Iii

    PIO-537A-i-MA015 User's Manual Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User's Manual can be downloaded from the Supermicro Web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend using SuperDoctor II. A-4 BIOS The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.

  • Page 43: How To Change The Confi Guration Data

    Often a text message will accompany it. (The AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".
  • Page 44 uper orkstation PIO-537A-i-MA015 User's Manual Notes...

  • Page 45: Appendix B Bios Beep Codes

    Appendix B: BIOS Beep Codes Appendix B BIOS Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue with bootup.
  • Page 46 uper orkstation PIO-737A-i-MA015 User's Manual Notes...

  • Page 47: Appendix C System Specifi Cations

    Appendix C: System Specifi cations Appendix C System Specifi cations Processors Two Intel E5-2600 processors in LGA 2011 sockets Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C600 BIOS 8 Mb AMI SPI Flash EEPROM Memory Capacity Sixteen DIMM sockets supporting up to 512 GB of registered/unbuffered ECC DDR3-1333/1066/800 LRDIMMs...
  • Page 48 uper orkstation PIO-737A-i-MA015 User's Manual Chassis SC733TQ-665B (Mid-tower) Dimensions: (WxHxD) 7 x 16.8 x 20.9 in. (178 x 427 x 531 mm) Weight Gross (Bare Bone): 43 lbs. (19.5 kg.) System Cooling One 12-cm chassis fan System Input Requirements AC Input Voltage: 100-240 VAC Rated Input Current: 10A (100V) to 5A (240V) Rated Input Frequency: 50/60 Hz Power Supply...
  • Page 49 Appendix C: System Specifi cations Notes...
  • Page 50 PIO-737A-i-MA015 User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
