Motorola TC55 User Manual page 156

156 | Technical Specifications
Item
Memory
Output Power (USB)
User Environment
Operating Temperature
Storage Temperature
Charging Temperature
Humidity
Drop Specification
Tumble Specification
Sealing
Wireless WAN Data and Voice Communications
Wireless Wide Area Network
(WWAN) radio
Frequency band
GPS
Wireless LAN Data Communications
Wireless Local Area Network
(WLAN) radio
Data Rates Supported
Operating Channels
Security
September 2013 | MN000015A01
Description
1 GB RAM, 8 GB Flash
300 mA
–10 °C to 50 °C (14 °F to 122 °F)
-40 °C to 70 °C (-40 °F to 158 °F)
0° C to 40° C (32 °F to 104 °F)
5% to 95% RH non-condensing
Multiple 1.2 m (4 ft.) drops per MIL-STD 810G specifications.
With protective boot: Multiple 1.2 m (4 ft.) drops to concrete across the operating
temperature range.
150 0.5 m (1.5 ft.) tumbles (300 drops);
With protective boot: 300 0.5 m (1.5 ft.) tumbles (600 drops); per applicable IEC
tumble specifications.
IP67 per applicable IEC sealing specifications.
4G LTE, HSPA+, DC-HSPA, EDGE/GPRS/GSM
EDGE/GPRS/GSM: 850/900/1800/1900 MHz
HSPA+ Americas: 850/1900/1700-2100 + 900/2100 MHz
HSPA+ Rest of the World: 900/2100 + 850/1900 MHz
LTE Americas: FDD2, FDD4, FDD5, FDD17
Integrated, Autonomous, Assisted-GPS (A-GPS), GLONASS
®
IEEE 802.11a/b/g/n with internal antenna
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5, 13, 19.5, 26, 39, 52, 58.5, 65 Mbps
Note that 802.11n data rates may be higher.
Channel 36-165 (5180 – 5825 MHz), Channel 1-13 (2412-2472 MHz); actual
operating channels/frequencies depend on regulatory rules and certification agency
Security Modes: Legacy, WPA and WPA2
Encryption: WEP (40 and 128 bit), TKIP and AES
Authentication: TLS, TTLS (MS-CHAP), TTLS (MS-CHAP v2), TTLS (PAP),
PEAP (MS-CHAP v2), PEAP (GTC).
Table continued...
