LV-671Z User's Manual
Appendix C <System Resource>
C.1 <I/O Address Map>
Address Range
x0000 - x000F
x0010 - x001F
x0020 - x0021
x0022 - x003F
x0040 - x0043
x0044 - x005F
x0060 - x0060
x0061 - x0061
x0062 - x0063
x0064 - x0064
x0065 - x006F
x0070 - x0073
x0074 - x007F
x0080 - x0090
x0091 - x0093
x0094 - x009F
x00A0 - x00A1
x00A2 - x00BF
x00C0 - x00DF
x00E0 - x00EF
x00F0 - x00FF
x0170 - x0177
x0170 - x0177
x01F0 - x01F7
x01F0 - x01F7
x0294 - x0297
x02F8 - x02FF
x0376 - x0376
x0376 - x0376
x0378 - x037F
x03B0 - x03BB
x03C0 - x03DF
x03F0 - x03F5
x03F6 - x03F6
x03F6 - x03F6
x03F7 - x03F7
I/O Address Map
Device
Direct Memory Access Controller
Motherboard Resource
Programmable Interrupt Controller
Motherboard Resource
System Clock
Motherboard Resource
Standard 101/102-Key or Microsoft Natural Keyboard
System Speaker
Motherboard Resource
Standard 101/102-Key or Microsoft Natural Keyboard
Motherboard Resource
System CMOS/ Real Time Clock
Motherboard Resource
Direct Memory Access Controller
Motherboard Resource
Direct Memory Access Controller
Programmable Interrupt Controller
Motherboard Resource
Direct Memory Access Controller
Motherboard Resource
Numeric Data Processor
Intel(R) 82801DB Ultra ATA Storage Controller - 24CB
Secondary IDE controller (dual fifo)
Intel(R) 82801DB Ultra ATA Storage Controller - 24CB
Primary IDE controller (dual fifo)
Motherboard Resource
Communication Port (COM2)
Intel(R) 82801DB Ultra ATA Storage Controller - 24CB
Secondary IDE controller (dual fifo)
Printer Port (LPT1)
Intel(R) 82852/82855 GM/GME Graphics Controller
Intel(R) 82852/82855 GM/GME Graphics Controller
Standard Floppy Controller
Intel(R) 82801DB Ultra ATA Storage Controller - 24CB
Primary IDE controller (dual fifo)
Standard Floppy Controller
System Resource
51
