LV-671Z User's Manual
2.14 <Switch and Indicator>
Connector: JFRNT
Type: onboard 14-pin (2 x 7) 2.54-pitch header
Function
IDE LED
Reset
Power
Button
Switch and Indicator
Signal
PIN
VCC
1
Active
3
Reset
5
GND
7
N/C
9
PWRBT
11
5VSB
13
Signal
2
VCC
4
N/C
6
GND
8
VCC
10
N/C
12
N/C
14
SPKIN
Hardware Setup
Function
Power
LED
Speaker
JFRNT
1
14
33
