LV-671Z User's Manual
VGA Display Interface
Chipset
Frame Buffer
Display Type
Connector
*Under Windows 98/ME/2000/XP/Server2003 or Linux kernel 2.4 later
Ethernet Interface
Chipset
Type
Connector
Audio Interface
Chipset
Interface
Connector
Solid State Disk Interface
Flash Type
Capacity
Expansion Interface
Slim PCI Slot
Mini-PCI
Mini-AGP
Product Specification
Intel 852GM GMCH built-in Intel Extreme Graphics Technology
With 133MHz VGA core and 256-bit 3D engine
Intel DVMT (Dynamic Video Memory Technology) 2.0 up to
64Mbytes shared with system*
CRT and LCD monitors for analog display
24-bit single/dual channel LCD panel for digital display
External DB15 female connector on rear I/O panel
Internal 40-pin LVDS connector
Intel PRO/1000+ LAN interface with Intel 82540EM
10Base-T / 100Base-TX/1000Base-T,
auto-switching Fast Ethernet
Full duplex, IEEE802.3U compliant
External RJ45 connector with LED on rear I/O panel
Intel ICH4 with REALTEK ALC655 AC97 3D audio codec
5.1 channel 3D audio with front (R/L), rear (R/L), center and bass
Optical Fiber digital audio encoding signal output
Optional external three phone jack for 5.1 channel audio onboard
External Amplified Speaker output jack on rear panel
External SPDIF connector on rear panel
Internal 10-pin header for line-in/-out, MIC-out, 4-pin header for
CD-in
Compact Flash Type-I/II for Compact Flash Card or IBM Micro Drive
Up to 1GB flash memory
One slim type PCI slot supports up to 2 bus master PCI
32-bit, 33MHz
One Mini-PCI socket with 32-bit, 33MHz for LV-671ZMP series
One Mini-AGP socket with DVO bus for LV-671ZMA series
Introduction
11
