Chapter 2 <Hardware Setup>
This chapter contains the information for installation of hardware. The install procedure
includes jumper settings, CPU and memory installation, fan, I/O and panel connections.
2.1 <Connector Location>
CN_BPWR CN_INV DIMM
MINI_AGP
MINIPCI
CN_IR
CPUFAN
CN 12V
DC_IN
Connector Location
IDE1
CN_LVDS
CN_2ND_IO
PS/2
Printer
VGA
SPEAKER SP/DIF Dual_USB PCMCIA
IDE2 CN_USB1 CN_USB2
CN_LAN2
LAN
COM2/1
Hardware Setup
CN_SPWR
JFRNT
SYSFAN
CN_DIO
PCI
FDD
CN_WOL
CN_AUDIO
CDIN
