LV-671Z User's Manual
Connector: IDE2
Type: 44-pin (22 x 2) box header
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
44
Description
Reset
D7
D6
D5
D4
D3
D2
D1
D0
Ground
REQ
IOW-/STOP
IOR-/HDMARDY
IORDY/DDMARDY
DACK-
IRQ
A1
A0
CS1
IDEACT-
VCC
Ground
2
1
Pin Description
2 Ground
4 D8
6 D9
8 D10
10 D11
12 D12
14 D13
16 D14
18 D15
20 N/C
22 Ground
24 Ground
26 Ground
28 IDESEL
30 Ground
32 N/C
34 SD
36 A2
38 CS3
40 Ground
42 VCC
44 Ground
I/O Port Pin Assignment
44
43
IDE Port
